Home > Electrical & Electronics > Sensor > Pressure Sensor > With High Precision Compression Load Cell With Module/GS348-M

With High Precision Compression Load Cell With Module/GS348-M

Name: With High Precision Compression Load Cell With Module/GS348-M
Brand: GOLDSHINE
SKU: 128763703
Availability: InStock

Ningbo Goldshine Electronic Co., Ltd.

With High Precision Compression Load Cell With Module/GS348-M thumbnail-1

With High Precision Compression Load Cell With Module/GS348-M photo-1

US$ 20 - 800 MOQ: 10 Sets

Key Specifications

Get Latest Price

Place of Origin:

Zhejiang, China

Brand Name:

GOLDSHINE

Model Number:

GS348-M

Contact Supplier Request Quote Chat Now

Payment & Shipping

Payment Methods:

Port of Shipment:

Ningbo or Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Zhejiang, China

Brand Name GOLDSHINE

Model Number GS348-M

Usage Pressure Sensor

Theory Resistance Sensor

Output Analog Sensor

Product Characteristics:

Shear beam load cells GS348-M series we can produce with analog load cells, digital load cells, wireless load cells, stainless steel load cells, alloy steel load cell, low profile scale beam load cells. Easy installation and it is suitable for floor scale, automobile test facilities, hopper scale, digital floor scale, floor weighing scale, floor balance scale, frameless floor ,frame type floor scale, explosion-proof floor scale, moveable floor scale, cattle scales, pit scale, track scale, digital platform balances, digital weight balance, digital scale balance,digital precision balance,digital counting balance,digital electronic balance,digital body balance, platform balances and other electronic weighing devices.

Technical Parameter:

Rated Load:	0.1/0.2/0.3/0.5/1/2/3/5t
Sensitivity:	(2.0±0.1%) mV/V ,(3.0±0.1%) mV/V
Combined Error:	±0.02% F.S
Creep Error(30min)	±0.02% F.S
Zero Balance:	±1% F.S
Tco:	±0.02% F.S/10°C
Tc Span:	±0.02% F.S/10°C
Input Resistance:	385±5Ω
Output Resistance:	352±2Ω
Insulation Resistance:	≥5000MΩ
Operating Temperature Range:	-30~+70°C
Maximum Safe Over Load:	150%F.S
Ultimate Over Load:	250%F.S
Recommend Excitation Voltage:	10~12V DC
Maximum Excitation Voltage:	15V DC
Sealing Class:	IP67/IP68
Element Material:	Alloy Steel/ Stainless Steel
Cable:	Length=L:6m
Citation:	GB/T7551-2008/ OIML R60
Mode Of Connection:	Red(Input+),Black(Input-),Green(Output+),White(Output-)-)
