Specifications
ncrete block production2.Japanese PLC control system
3.hydraulic vibration system
4.full automatic
5.ISO9001:2008
building machines new technologic hydroform automatic concrete cement concrete block production
QTY 8-15 hydroform automatic concrete cement block brick making machine can produce all size of hollow blocks,solid bricks,just change the relevant moulds.
1Our Advantages of concrete block production
We are brick and block making machine manufacturer with 40 years professional experience. |
We can offer large scale, millde scale and small scale brick and block making machine. |
We have more than 40,000 square meters production area with over 200 workers. |
Welcome to visit Shenta factory. |
Shenta Machinery Equipment Co.,Ltd. (short for Shenta machine), we are specialized in concrete brick and
block making machine in China, as the most earliest and professional in cement brick and block making
machine since1973, we can offer you the brick & block making machine and production line with reliable
quality, professional technology, and sincere service. We have exported to Southeast asia, Africa, South
America, North America ,Russian , Europea and so on . all of our machiens running very well .
2 The main technical characteristics of concrete block production
1 |
The machine adopts hydraulic system and the working procedure is very even and dependable, hydraulic press together with effciently vibration make the shape,it which has high density and good quality. |
2 |
It is a practical machine that simple in structure, artistic in figure.especially suitable to the production of the standard bricks,it can produce various kinds of paver bricks,porous bricks, road bricks etc. |
3 |
The reasonable material proportion have the capacity of making high density standard bricks, what’s more,it can be piled up directly. |
3Raw Materials of concrete block production :
Cement—10%; |
Fly ash or refine stone powder or refine sand—38%; |
Crushed stone (diameter<15mm)—52% |
Materials such as sand, crushed stone, cement, dust and fly coal ash, cinder, gravel ..... |
Raw material |
crushed stone,sand,cement, dustand coal ,fly ash, cinder,slag, gangue,gravel, perlite, and other industrial wastes. |
Applied products |
concerte lid/hollow/cellular masonry products,paving stones with or without face mix, garden and landscaping products, slabs,edgers, kerbstones, grass blocks, slope blocks, interlocking blocks,etc. |
Applied fields: |
widely used in buildings,road pavers, squares, gardens, landscaping, city constructions ,etc |
4 main technical parameters of concrete block production
Outside Dimension (mm) |
5200x1900x2800 |
Operation Cycle (s) |
15~25 |
Main Machine Weight (Ton) |
9 |
Vibration Frequency (rpm) |
4300 |
Power Consumption (Kw) |
45.2 |
Vibration Force (Kn) |
100 |
Pallet Dimension (mm) |
900x900x25 |
Vibration Power (kW) |
22 |
Operator quantity |
5 people |
Land required |
5000m2 |
5 Technical parameters of concrete block production
Brick Size |
Blocks/Mould |
Blocks/Hour |
Blocks/Shift |
Remark |
Hollow Brick (400x200x200mm) |
8 |
1,150~1,920 |
9,200~15,300 |
|
Hollow Brick (400x150x200mm) |
10 |
1,440~2,400 |
11,500~19,200 |
|
Hollow Brick (400x100x200mm) |
14 |
2,020~3,360 |
16,200~26,800 |
|
Hollow Brick (390x190x190mm) |
8 |
1,150~1,920 |
9,200~15,300 |
|
Porous Brick (240x115x90mm) |
18 |
2,600~4,320 |
20,700~34,500 |
|
Solid Brick (240x53x115mm) |
36 |
6,480~8,640 |
52,000~69,000 |
|
6 shenta user production line :
8 if you are interested our block making machine ,please contact Kelly!
Buying tips:
when you want to buy, please tell me:
1 Your bricks size ( length, width and height);
2 Your bricks pricture(If you have);
3 Your production bricks /day;
