Help CenterCCC Rubber Sheathed Rubber Flexible Cable
Related Products
-
CCC Rubber Sheathed YZ YZW 300 500v Flexible CableUS$ 1 - 10MOQ: 1000 Meters -
CCC Rubber Sheathed YZ YZW 300/500V Rubber CableUS$ 1 - 10MOQ: 1000 Meters
-
CCC Rubber Sheathed YC YCW 450/750v Control CableUS$ 1 - 10MOQ: 1000 Meters
-
CCC Rubber Sheathed YC YCW 450/750v CableUS$ 1 - 10MOQ: 1000 Meters
-
CCC Rubber Sheathed YC YCW 450/750v Rubber CableUS$ 1 - 10MOQ: 1000 Meters
Specifications
CCC Rubber sheathed rubber flexible cable1. Rubber sheathed
2. CCC approved
3. Rating: 300/500V
4. Color: Black
CCC Rubber sheathed rubber flexible cable
1. Rubber sheathed
2. CCC approved
3. Rating: 300/500V 60°C
4. Color: Black
| No.of conductor |
Conductor
|
Insulation thickness (mm) |
Sheath thickness (mm) |
Overal diameter (mm) |
Max Conductor resistance at 20°C (Ω/km)
|
||
| Normal Area (mm²) |
Construction (No. /mm) |
Bare |
Tinned |
||||
| 2 | 0.75 | 24/0.20 | 0.6 | 0.8 | 6.4±0.2 | 26.0 | 26.7 |
| 1.0 | 32/0.20 | 0.6 | 0.9 | 7.0±0.2 | 19.5 | 20.0 | |
| 1.5 | 30/0.25 | 0.8 | 1.0 | 8.7±0.2 | 13.3 | 13.7 | |
| 2.5 | 49/0.25 | 0.9 | 1.0 | 10.2±0.3 | 7.98 | 8.21 | |
| 4.0 | 56/0.30 | 1.0 | 1.2 | 12.2±0.3 | 4.95 | 5.09 | |
| 6.0 | 84/0.30 | 1.0 | 1.3 | 13.2±0.3 | 3.30 | 3.39 | |
| 3 | 0.75 | 24/0.30 | 0.6 | 0.9 | 7.0±0.2 | 26.0 | 26.7 |
| 1.0 | 32/0.20 | 0.6 | 0.9 | 7.4±0.2 | 19.5 | 20.0 | |
| 1.5 | 30/0.25 | 0.8 | 1.0 | 9.1±0.2 | 13.3 | 13.7 | |
| 2.5 | 49/0.25 | 0.9 | 1.1 | 10.8±0.3 | 7.98 | 8.21 | |
| 4.0 | 56/0.30 | 1.0 | 1.2 | 13.3±0.4 | 4.95 | 5.09 | |
| 6.0 | 84/0.30 | 1.0 | 1.3 | 15.4±0.5 | 3.30 | 3.39 | |
| 4 | 0.75 | 42/0.15 | 0.6 | 0.9 | 7.7±0.2 | 26 | 26.7 |
| 1.0 | 32/0.20 | 0.6 | 0.9 | 8.0±0.2 | 19.5 | 20.0 | |
| 1.5 | 48/0.20 | 0.8 | 1.1 | 10.1±0.3 | 13.3 | 13.7 | |
| 2.5 | 49/0.25 | 0.9 | 1.2 | 12.1±0.4 | 7.98 | 8.21 | |
Product Picture:
Factory Picture:
Certificated Approval:
CCC, UL/CUL,CEE,VDE,GS,NF,BS,CSA,PSE,SAA,SABS,SEV,NBR,EK,KEMA and so on.
QC Team :
A QC team with more than 20 professional and technical personnel. To ensure 100% products checking.
Material: Strictly control of material using, meet international requested standards.
Semi-finished products inspection: Product inspection before 100% finished.
Production line test: With work team or data engineer who will inspect machines and lines at fixed period.
Finished Product Inspection: Quality and property test before products are packed and loaded.
Market:
Contact:
We will reply your email within 24 hours.
You can call us at any time if there is any question, thanks.
If you want to know more information, pls do not hesitate to contact us!
Email: tina(at)
