China CNC Machine Tools 300D

FOB Price

US$ 5,000 - 20,000 / Set

1 Set(Min. Order)

Port Qingdao
Payment TermsT/T L/C D/P D/A Credit Card PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Type	Other, Milling Drilling Compound CNC lathe,
CNC or Not	CNC	Automatic Grade	Automatic
Max. Swing Diameter	300mm	Place of Origin	Shandong, China
Brand Name	HaiShu	Model Number	CNC300D
Voltage	380V	Power(W)	3.7kw
Dimension(LWH)	2030X1626X1730mm	Weight	1500KG
Certification	CE Certificate	After-sales Service Provided	Overseas service center available

Product Description

Multifunction machine tool,Milling Drilling CNC compound lathe,CNC machine tools,CNC300D

Item	parameters
Maximum turning diameter over bed	Φ300 mm
Maximum turning diameter over skateboard	Φ120 mm
X-axis maximum stroke	280 mm
Z-axis maximum stroke	320 mm
Rail width	325mm
Spindle head model	ISOA2-5 / MT5
Spindle bore	Φ41mm
Speed	5000r/m
Chuck	Φ160 mm(Optional collet)
Turret type	row tool
Tool shank specifications	20×20 mm
Knife block center high	61 mm
Main motor power	3.7 kw(Servo)
X-axis maximum torque	5 Nm
Z-axis maximum torque	7.5 Nm
Foot of the bed to spindle center height	935 mm
Power head clamping tool diameter	Φ2~13mm
Power head speed range	3000~12000rpm
Power head power	1.5kw
The machine can clamp the tool number	8
Oversize	2030×1626×1730mm
Net weight	1500 kg

Packaging & Shipping

CNC machine tool exports Packing: Export Packing Machine fumigation
Transportation: If the customer does not have special requirements, CNC machine tools and engine test equipment exports, usually automotive logistics transport to Qingdao port, transport to the nearest port customer specified by ship.

Our Services

Thank you for your interest in our production of CNC machine tool products, in order to protect your legal rights, from you for purchasing our CNC machine tools worries, we like all of our customers to purchase CNC machine tool products, on product quality and after-sales service to make the following committed to:
1, three bags a year, life-long service
2, free training operators
3, receiving customer feedback, provide solutions within 24 hours
4, CNC equipment parts are used in the world and China's well-known brand manufacturers
5, the company exports are the new equipment CNC equipment, packaging before the error, have good debugging, fully meet customer requirements, before allowing shipment

Certifications

Tuv certification and CE certification

Contact Us

Taian Haishu Machinery Co., Ltd.: Contact namebaoling su
Chat Now; Phone86-0538-8606169; AddressZhouwangzhuang Village, Shankou Town, Daiyue Dist.
