Automatic Lathes CK0680A Machine Tool
- QINGDAO
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
HAISHU Customize Lathe,Milling Drilling Multifunction Lathe,CNC Machine Tools,CNC300D
-
Multifunction Machine Tool,Milling Drilling Composite Lathe,CNC Machine Tools,CNC300D
-
HAISHU CK0640A Precision Power Head Numerical Control Lathe Numerical Control Lathe Service
-
Cheap Small CNC Lathe Price for Sale Metal Lathe Factory in China
-
Manufacturers to Produce Quality and Reliable Small CNC Lathe
-
Low Cost Lathe CNC Machines for Sale With GSK SIEMENS FANUC Controller CK6136A
Product Details
| Condition | New | Type | Horizontal | |
| CNC or Not | CNC | Automatic Grade | Automatic | |
| Max. Swing Diameter | 300mm | Place of Origin | Shandong, China | |
| Brand Name | HaiShu | Model Number | Horizontal Lathe | |
| Voltage | 380V | Power(W) | 4KW | |
| Dimension(L*W*H) | 1550x1000x1500 | Weight | 1500KG | |
| Certification | TUV | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Automatic lathes CK0680Amachine tool
1. Specifications
Items |
| Specifications | |||
CK0660A | CK0680A | CK06100A | CK06110A | ||
Max.swing over bed | mm | Φ300 | |||
Max.swing over carriage | mm | Φ150 | |||
Max. length of work piece | mm | 220 | |||
Spindle head form |
| A2-5 | |||
Spindle bore | mm | Φ70 | Φ90 | Φ110 | Φ120 |
Trombone bore | mm | Φ60 | Φ80 | Φ100 | Φ110 |
Guide rail width | mm | 260 | 300 | 300 | 300 |
Guide rail length | mm | 840 | 880 | 880 | 880 |
X / Z axis repeat positioning accuracy | mm | 0.012/0.013 | |||
X-axis max motion traveling schedule | mm | 320 | |||
Z- axis max motion traveling schedule | mm | 220 | |||
X-axis fast moving speed | m/min | <P ter="" ,="">5 | |||
2. Characteristics
2.1 The base of the machine tool, lathe bed guide rail structure reasonable wide, berth box adopts thermal type structure design, the more effectively improve the stability of the machine and the axis of stability.
2.2 Before and after the spindle bearings are used high precision ball bearing, contact with diagonal work good stability, high load bearing.
2.3 The wear-resisting cast iron casting, guide rail and the super audio quenching and fine grinding, to ensure the long-term stability of machining precision and service life.
2.4 X axis and Z axis screw all use of four point one-like for structure design, ensure guide in the work more smoothly and not by lateral force influence, in processing products when dragging plate cutting big and small dragging plate more smoothly and vibrate resistance, it is more convenient to maintain better.
2.5 Z to guide with double swallow tail the fully closed structure design, in machine tool can work better for protection of guide rail, top end before and after sit move more stable and convenient and quick.
2.6 Spindle flange connection plate adopts the international standard design, ordinary three claws chuck and hydraulic chuck installation more convenient and quick.
3. Application
The machine can be widely used for valve/plumbing/auto parts and other metal parts to the finishing. multiple products a circular/end face/hole/cutting/any cone/sphere and various metric system of automatic thread cutting.
4,Standard configuration
system:GSK928
Pneumatic chuck
Row knives
5,Optional configuration
system:GSK980,KND,Siemens,Fanuc
Manual or Power tailstock
Electric turret
Thank you for your interest in our production of CNC machine tool products, in order to protect your legal rights, from you for purchasing our CNC machine tools worries, we like all of our customers to purchase CNC machine tool products, on product quality and after-sales service to make the following committed to:
1, three bags a year, life-long service
2, free training operators
3, receiving customer feedback, provide solutions within 24 hours
4, CNC equipment parts are used in the world and China's well-known brand manufacturers
5, the company exports are the new equipment CNC equipment, packaging before the error, have good debugging, fully meet customer requirements, before allowing shipment
CNC machine tool exports Packing: Export Packing Machine fumigation
Transportation: If the customer does not have special requirements, CNC machine tools and engine test equipment exports, usually automotive logistics transport to Qingdao port, transport to the nearest port customer specified by ship.

Number Taian Hai Machinery Manufacturing Co., Ltd. (Tai'an City Hite machinery manufacturing limited liability company) is manufacturing of CNC machine tools and engine testing equipment professional enterprises, scientific research, production and marketing of high-tech enterprises. The company's CNC machine tools and test equipment division division, has passed the ISO9001: 2008 international quality management system certification and the European CE certification. Strong technical force, has a group of young and promising engaged in CNC machine tools and test equipment design and manufacturing, electrical design and application of numerical control technology and software development professional and technical personnel. The use of advanced two-dimensional and three-dimensional CAD computer-aided design, product innovation, equipment, numerical control, management information, has become the domestic industry technology leader.
CNC machine tools are: CNC lathes, turning centers, machining centers, CNC lathes instrumentation, CNC lathes, CNC machine tools, automatic feeding CNC lathes, lathes, automatic lathes, mini lathes, woodworking lathes, woodworking tools, small machine tools, CNC light machine tools, machine tools, precision machine tools. Lathe-ray machines, precision lathes, small CNC lathes, CNC lathes and other economy.
Test equipment are: injection pump test bench, injector test bench, common rail injector test bench, common rail system test bench and so on.
Number Taian Hai Machinery Manufacturing Co. NC machine model is complete, it can be customized according to customer all kinds of special tools workpiece
Tuv certification:
CE certification:

Contact Us
- Taian Haishu Machinery Co., Ltd.
- Contact namebaoling su Chat Now
- Phone86-0538-8606169
- AddressZhouwangzhuang Village, Shankou Town, Daiyue Dist.
