Specifications
Rubber Refining Machine1 rubber calendaring and pressing
2 roller made of alloy cast iron
3 overload protection device
Roll Diameter 450 Rubber Refining Machine/Machinery
nstruction
This machine consists of Base,Rack,Gland,Rollers,Bearing,Transmission device,Lubrication device,Decelerator,Adjustment device of the roller temperature,Emergency shutdown device and brake rigging and etc.
2.uses
It is mainly used for plasticating and mixing of rubber or plasticsect., warming and sheeting rubber compound, cracking and refining ofreclaimed rubber.
3.Features
A The roll adopts the vanadium titanium metal alloy chilled cast iron and its surface is hard and wear-proof. The internal cavity is processed to make temperature well proportioned on the roll surface.
BThe machine is equipped with an overload protection device to prevent the main components from being damaged.
C The machine is also equipped with an emergency brake device. When an emergent arises, just draw the safety pull rod, and the machine will stop immediately. It is safe and reliable.
D. The transmission system adopts a hardened tooth-surface reducer, which has a compact structure with higher transmission efficiency, lower noise and longer service life.
E. The base frame is a whole framework, which is convenient for installation.
F. Stock bender for direct rubber sheet and knife to cut as your need to assemble.
G.Auto-lubrication system for greese or oil and match bearing bush
Version and its Technique Parameters:
| Technique Parameters | XK-160 | XK-250 | XK-400A | XK-450A | Xk-450 | XK-560A | XK-550B | XK-660 | XKY-660 |
| Roll diameter(mm) | 160 | 250 | 400 | 450 | 450 | 560/510 | 550 | 660 | 660 |
| Roll length(mm) | 320 | 620 | 1000 | 1200 | 1200 | 1530 | 1500 | 2130 | 2130 |
| Front roll surface speed(m/min) | 8.95 | 15.3 | 18.65 | 18.65 | 23.47 | 27.87 | 28.32 | 28.6 | 32.53 |
| Friction ratio | 1:1.35 | 1:1.1 | 1:1.27 | 1:1.27 | 1:1.27 | 1:1.2 | 1:1.22 | 1:1.24 | 1:1.09 |
| Max.nip | 4.5 | 8 | 10 | 15 | 15 | 15 | 15 | 15 | 15 |
| Feeding capacity per | 1-2 | 10-15 | 18-35 | 25-50 | 25-50 | 35-50 | 50-60 | 165 | 165 |
| Power | 5.5 | 18.5 | 37 | 55 | 55 | 90 | 110 | 160/245 | 160/245 |
| Size(lenght*width*height)(mm) | 1226*830*1295 | 3400*1600*1500 | 4350*1850*1780 | 5200*2380*1940 | 5670*2390*1670 | 6180*2280*1970 | 5870*2470*2040 | 7460*3660*2080 | 7465*3660*2080 |
| Weight(Kg) | 1280 | 3300 | 7860 | 12600 | 11940 | 22500 | 27000 | 49940 |
49000
|
Based on the ideas of High quality and Credit, we strictly control the quality of the
products, and constantly improve our powerful technical support and personnel
training to per customers. Mutual benefit is our aim and customers' satisfaction is our
success.
Picture one : XK-160 lab rubber mixing mill . Mainly used for lab use
picture two : XK-250 rubber mixing mill . production capacity is about 150 kg/h
picture three : xk-360 rubber mixing mill .Production is about 250 kg/h
picture four : xk-400 rubber mixing duction is about 350 kg/h . From this model , we begin distiguish configuration . NYLON , COPPER , ROLLER BALL BEARING.
picture five:XK-450 rubber mixing mill . two configuration , stock blender is choosed . 500 kg/h
picture six : XK-560 . two configuration , stock blender . production is 500 KG/H
picture eight : XK-660 rubber mixing mill . production capacity 2000 kg/h
