Specifications
Two Rolls Mixer/Open Mixing Mill1.roll:cold hard cast iron
ucer:hard tooth surface
3.a load test running
Two Rolls Mixer/Open Mixing Mill with Stock Bender
We are Qingdao Yahua Machinery CO.,LTD. Our main products are plate vulcanizing machine, curing press, rubber machine, conveyer belt vulcanizing press, Rubber crushing mill, Rubber refining mill, rubber tiles vulcanizing press, tire building machine, rubber kneader, two-roll mixing mill and so on.
The products have been exported to many countries, such as America, Canada, Australia, South Korea, and Southeast Asia, Middle-east, etc .
If you interested in our products mentioned above. Kindly let us know by return email.
Structure features:
1. The roll adopts the vanadium titanium metal alloy chilled cast iron and its surface is hard and wear-proof. The internal cavity is processed to make temperature well proportioned on the roll surface.
2. The machine is equipped with an overload protection device to prevent the main components from being damaged.
3. The machine is also equipped with an emergency brake device. When an emergent arises, just draw the safety pull rod, and the machine will stop immediately. It is safe and reliable.
4. The transmission system adopts a hardened tooth-surface reducer, which has a compact structure with higher transmission efficiency, lower noise and longer service life.
5. The base frame is a whole framework, which is convenient for installation.
6. Stock bender for direct rubber sheet and knife to cut as your need to assemble.
7. Auto-lubrication sysytem for greese or oil and match bearing bush.
8. Qingdao Yahua machinery manufacting Co., Ltd is a the partner of Acooperating Unit Of China Science institute, and also we export rubber machines to all the world, such like south Asia, south America, Africa ect. please contact us for the long-term business.
Version and its Technique Parameters:
| Technique Parameters | XK-160 | XK-250 | XK-400A | XK-450A | Xk-450 | XK-560A | XK-550B | XK-660 | XKY-660 |
| Roll diameter(mm) | 160 | 250 | 400 | 450 | 450 | 560/510 | 550 | 660 | 660 |
| Roll length(mm) | 320 | 620 | 1000 | 1200 | 1200 | 1530 | 1500 | 2130 | 2130 |
| Front roll surface speed(m/min) | 8.95 | 15.3 | 18.65 | 18.65 | 23.47 | 27.87 | 28.32 | 28.6 | 32.53 |
| Friction ratio | 1:1.35 | 1:1.1 | 1:1.27 | 1:1.27 | 1:1.27 | 1:1.2 | 1:1.22 | 1:1.24 | 1:1.09 |
| Max.nip | 4.5 | 8 | 10 | 15 | 15 | 15 | 15 | 15 | 15 |
| Feeding capacity per | 1-2 | 10-15 | 18-35 | 25-50 | 25-50 | 35-50 | 50-60 | 165 | 165 |
| Power | 5.5 | 18.5 | 37 | 55 | 55 | 90 | 110 | 160/245 | 160/245 |
| Size(lenght*width*height)(mm) | 1226*830*1295 | 3400*1600*1500 | 4350*1850*1780 | 5200*2380*1940 | 5670*2390*1670 | 6180*2280*1970 | 5870*2470*2040 | 7460*3660*2080 | 7465*3660*2080 |
| Weight(Kg) | 1280 | 3300 | 7860 | 12600 | 11940 | 22500 | 27000 | 49940 |
49000
|
Picture one : XK-160 lab rubber mixing mill . Mainly used for lab use
picture two : XK-250 rubber mixing mill . production capacity is about 150 kg/h
picture three : xk-360 rubber mixing mill .Production is about 250 kg/h
picture four : xk-400 rubber mixing duction is about 350 kg/h . From this model , we begin distiguish configuration . NYLON , COPPER , ROLLER BALL BEARING.
picture five:XK-450 rubber mixing mill . two configuration , stock blender is choosed . 500 kg/h
picture six : XK-560 . two configuration , stock blender . production is 500 KG/H
picture eight : XK-660 rubber mixing mill . production capacity 2000 kg/h
Brief Introduction of our factory:
Qingdao Yahua Machinery Co.,Ltd is situated west of Jiaozhou and east of Qingdao Economic Developing Zone, near No.,204 National Road and Tongsan High Way.
We are very professional rubber machinery factories here. OUr products are well-known from different areas in domestic and overseas.
Contact Person: Bella Xue
Office Phone: 0532-83132191
Fax Phone: 0532-83137817
Mobile phone:13325017346
