Specifications
Stable performance Excellent quality &stable performanceHigh products qualification rate
Reasonable price & on time delivery
Rubber Moulding Press/Rubber Sealing and Bushing Washer Vulcanizing Press
1- Usage:
This vulcanizing machine is used for all kinds of vulcanizing mould, rubber and plastic .
2- Features:
Being a column structure and downward pressing type, the heating plate opens by the self-weight of the heating plate, platform and plunger. The rising of the plunger makes the heating plate close while the hydraulic oil provides the pressure.
This engine base is combined together with the cylinder and base frame, which is made of ductile iron to increase the cylinder intensity and a brad ability. The cylinder is fitted with the sealing washer made of the oil-resisting rubber for the sealing purpose.
By moving the operational handle of the control valve to the two different positions, the heating plate can open and close.
It uses the electric pipe for heating, thus makes the workshop clean with easy and reliable operation.
3- Certification: ISO9001
As a bigger and quality rubber machine manufacture,we gain more and more clients. If you need ,please contact us as soon as possible.
Parameters/version |
XLB400*400*2 |
XLB500*500*2 |
XLB600*600*2/4 |
Mould closing force |
0.5 |
0.8 |
1.0 |
Hot plate spacing |
125 |
125 |
125 |
Hot plate layer |
2 | 2 |
2/4 |
Plunger stroke |
250 |
250 |
250/500 |
Heating way |
Electricity/steam |
Electricity/steam |
Electricity/steam |
Main motor power |
2.2 |
2.2 |
2.2 |
The thermal power |
3kw/board |
3kw/board |
7.5kw/board |
Size(l*w*h) |
1600*400*1440 |
1450*690*1818 |
1880*780*1660 |
Weight(kg) |
1500 |
1800 | 2500/3100 |
Platen unit area pressure |
3.13 |
2.52 |
2.78 |
| Model | XLB-1800X12000*2 | XLB-1800X10000*2 | XLB-1600X10000*2 | XLB-1600X10000*1 | |
| Heating platen size (mm) | 1800*12000 | 1800*10000 | 1600*10000 | 1600*10000 | |
| Nominal total pressure (mn) | 74 | 72 | 56 | 64 | |
| Platen unit pressure (mpa) | 3.4 | 4 | 3.5 | 4 | |
| Ram diameter (mm) | 500 | 500 | 450 | 500 | |
| Ram Qty (pc) | 18 | 18 | 18 | 18 | |
| Max. Ram stroke (mm) | 400 | 300 | 400 | 300 | |
| Clamping force (mn) | 1.2 | 1.5 | 1.2 | 1.2 | |
| Tensioning force (mn) | 1.1 | 1.2 | 1.1 | 1 | |
| Steam pressure (mpa) | 0.63 | 0.6-0.8 | 0.63 | 0.6-0.8 | |
| Cooling water pressure (mpa) | 0.3 | 0.3 | 0.3 | 0.3 | |
| Control form | PLC | PLC | PLC | PLC | |
| Overall dimension of main machine | Length (mm) | 12000 | 1000 | 10000 | 10000 |
| Width (mm ) | 2900 | 2740 | 2660 | 2560 | |
| Height (mm ) | 3930 | 3660 | 4120 | 3520 | |
We are Qingdao Yahua Machinery CO.,LTD. Our main products are plate vulcanizing machine, curing press, rubber machine, conveyer belt vulcanizing press, Rubber crushing mill, Rubber refining mill, rubber tiles vulcanizing press, tire building machine, rubber kneader, two-roll mixing mill and so on.
The products have been exported to many countries, such as America, Canada, Australia, South Korea, and Southeast Asia, Middle-east, etc .
If you interested in our products mentioned above. Kindly let us know by return email.
Contact person:Bella Xue
Skype:bella.xue1990
Phone:0532-83132191/83137817
