Help CenterDown Stroke Type Four Column Hydraulic Press/Flat Vulcanizing Press
Related Products
-
Rubber Sole Machine/Pillar Plate Vulcanizing Press/Electrical Rubber VulcanizerUS$ 3,500 - 26,750MOQ: 1 Set -
Automatical Rubber Sealing Washer Vulcanizing Machine/Rubber Mat Making Machine/Rubber Mould Press and Shaping MachineUS$ 6,500 - 28,600MOQ: 1 Set
-
Automatic Vulcanizing Press For Endless BeltUS$ 6,500 - 28,600MOQ: 1 Set
-
Rubber Anti-Vibration Molding Press/Rubber Products Making Machine/Vulcanizing PressUS$ 2,780 - 68,200MOQ: 1 Set
-
Automatically Open Mould Rubber Vulcanizing Press/Conveyor Belt Curing PressUS$ 6,500 - 28,600MOQ: 1 Set
Specifications
1.hydraulic press was passed the ISO9001.2.high quality, advanced technology, reasonable price and good reputation.
Rubber PlateVulcanizing press is the machinery which produce all kind of rubber products, and thermosetting plastic like as related specifications aseling products, projected rubber, rubber plate and so on.
This Machinery has three types: frame type, pillar type and jaw type. It is economical advantage of compact structure, high working pressure, and high producing efficency.
Model and its Parameter as follows:
XLB-DQ1200×1200×2 | XLB-DQ1300×2000×1 | XLB-Q1200×2500×1 | XLB-Q1500×2000×1 | XLB-Q2000×3000×1 | XLB-Q1400×5700×1 | |
Total pressure(MN) | 315t | 560t | 750t | 1000t | 1800t | 2800t |
Plate size(mm) | 1200×1200 | 1300×2000 | 1200×2500 | 1500×2500 | 2000×3000 | 1400×5700 |
Daylight(mm) | 200 | 400 | 400 | 400 | 400 | 400 |
Layer | 2 | 1 | 1 | 1 | 1 | 1 |
Piston stroke(mm) | 400 | 400 | 400 | 400 | 400 | 400 |
Plate unit area pressure (kg/ cm2) | 22 | 21.5 | 25 | 33.5 | 30 | 35 |
Main motor power(KW) | 3 | 8 | 9.5 | 11 | 26 | 43.5 |
Overall dimension (L×W×H)(mm) | 1685×1320×2450 | 2000×1860×2500 | 2560×1700×2780 | 2810×1550×3325 | 2900×3200×2860 | 2400×5800×3600 |
Weight (kg) | 9500 | 17000 | 20000 | 24000 | 66000 | 110000 |
Brief Introduction of our factory:
We are Qingdao Yahua Machinery CO.,LTD. Our main products are plate vulcanizing machine, curing press, rubber machine, conveyer belt vulcanizing press, Rubber crushing mill, Rubber refining mill, rubber tiles vulcanizing press, tire building machine, rubber kneader, two-roll mixing mill and so on.
The products have been exported to many countries, such as America, Canada, Australia, South Korea, and Southeast Asia, Middle-east, etc .
If you interested in our products mentioned above. Kindly let us know by return email.
Contact person:Bella Xue
Skype:bella.xue1990
Phone:0532-83132191/83137817
