Features:
The hot press is available for the decorative lamination on MDF board, Particle board,
HDF board and plywood etc.,especially for the lamination of furniture panels and laminate
floorings. The suitable materials are melamine paper, wear resistant paper, decorative cloth
and slice veneer etc
Technical parameter:
Model |
TLY214x8/12-IID |
Nominal pressure |
12000 KN |
Layer |
1 |
Layer space |
300mm |
Heating plate |
2 picecs |
|
Heating plate size |
1400x2600x120mm(up) |
1400x2600x100mm(down) | |
Main cylinder |
320mm x 6unit |
Closing time |
About 5 S |
Lifting cylinder |
110mm x 2 units |
Allow Max. pressure |
25 Mpa |
power |
37 KW |
Unit pressure |
39.5Kgf/cm2 |
Panel size |
1220x2440mm |
weight |
36000 Kg |
Overall deminsion |
3490x1400x3200mm |
Control systerm |
Automatic pump |
Framework |
combination |
