Standalone access control kaypad 125khz promixity metal rfid reader
Main Features :
.Low power consumption: Less than 30mA standby current
.Luminous keyboard: The night can also operate keyboard
.User capacity: Support 2, 000 users
.Independent password: Can use password which irrelevant with the card to open the door
.User modification password: Users can revise the door password
. Search speed: Charge to open the door time less than 0.1 S.
.Output short circuit protection: Electric lock or alarm output circuit within 100 μ S when shut
down automatically output
.Wiegand output: With Wiegand output interface, Wg26 card number or Wg4 buttons output
.Usable keyboard delete card number: After card is lost, usable keyboard delete card, Thoroughly
eliminate safety lapses
.The demolition alarm: Illegal dismantling machine, built-in alarm sound buzzer
.The bell button and interface: Key and circuit segregation, external any the doorbell.
Main specification :
Metal hosing and keypad with back light
Capacity: 2000 user
Waterproof degree:IP68
Working Voltage : DC12V-24V
Reading card: 125KHz
Three kinds of unlock way: password, card, password and card
Wiegand in/out, with external reader
Reading card distance: 5cm (thick card 8cm)
Size: 120*56*18mm
Model no |
Card style |
frequency |
Reading range |
JYA-H600EM-W |
EM |
125KHz |
5-15CM |
JYA-H600MF-W |
M.F |
13.56MHZ |
3-10CM |
