Product Details
Model Number : JYC-T2004B
Main Features :
.TCP/IP / RS485/232 communiction/single door Control four doors
.Can control enter and exit by read card
.20 000pcs cards management authority
.100 000pcs storage records
Main specification :
Communication |
TCP/IP / RS485/232 |
English Software database: |
SQL |
Description |
Control 1 door, in or out door by swiping card, or get in by swiping card and get out door by button |
Power Supply |
12VDC; 4-7A |
Power Consumption of Circuit Board |
Less than 100mA |
Input Format of Reader |
Wiegand 26/34 bit (All card reader with compatible protocol) |
Control Door and Readers |
4 doors by 4 readers |
Door opening time extending setting |
1-600 Seconds(adjustable) |
Operation Temperature |
-40°C-70°C |
Operation Humidity |
10-90 % RH , No Condensation |
Power interruption protection |
High Speed Memory, Records never lose |
Max Distance |
100M (suggestion distance 80m) |
Max Distance between Controllers |
Depand on network range |
Collocations |
PCB board, case, power, power line, serial port communication line, software, manual, certificate, key(2pcs), carton |
Alarm function |
Yes |
Fire and alarm linkage |
If no connection with the expansion board, only has software interface alarm, and drive the computer speaker. If connected with expansion board, is able to alarm by hardware, if connected with strengthened expansion board, then is able to Security alarm |
Open door in remote distance |
Yes |
Anti pass back and tail |
Yes |
Electronic map |
Yes |
Urgency locking |
Yes |
Keypad (card+passwor,password) |
Yes |
Unit Size |
160mm *106mm |
