High Presssure Vortex Gas Pump
US$ 120 - 150
MOQ: 10 Sets
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
GEBIAO
Model Number:
GB-2200
Payment & Shipping
Payment Methods:
Port of Shipment:
NINGBO /SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Place of Origin
Zhejiang, China
Brand Name
GEBIAO
Model Number
GB-2200
Theory
Vortex Pump
Structure
Single-stage Pump
Usage
Air Pump
Power
Electric
Standard or Nonstandard
Standard
Pressure
High Pressure
)Features for air pump
- motor :Europe standard ,with CCC certificate
- bearing purchased from NSK,japan ,FAG German,can be installed in front or build-in
- shaft sealing :free maintenance fluorine rubber or skeletion-type.
- protection grade IP54 and IP44,insulation grade B
- vibration counteract plate
- Dia-casting aluminum ,speed up hot emissions,less weight,fashion style.
- only wearing with bearing ,more reliable
- aluminum impeller ,side channel
- no oil,no pollution
- can installed vertical ,horizontal and lateral
- anticorrosive coating inside the water pump adds to lifespan
caution
- safety working condition : -10°C-40°C for three phase ,-5°C-40°C for single phase ,with good draught ,less dustand moisture,installed above water level ,should be prevent from rain when use outside.
- your air pump was usually designed with horizontal shaft,lifespan will be shortened when use vertically
- vibration dampening device or plate need to be added when place is not horizontal
- do not use besides flammable and explosive material
- filter need to be added if inlet tube do not connected with others ,clean regularly to prevent blockage
- weight of the add-on tubes can not be carried on the connecter of the air pump
- add-on tube and inlet should be connected with hose
- avoid sudden reduce or bent of tubes ,otherwise flow may unstable
- suggest to have back-up air pumps when long duration of use
- temperature of outlet will be very high under operation .please use heat-resistance or metal add-on tub,length should be at least 2m
- suggest to use only 65% of the technical parameter of each item.
Applications
it is used for planting aquarium plantaerating for seafood in hotels .restaurants .seafood booths and feeding pool etc.it's also used for air supply to spare parts of food machine .medical instrument.paper cutters .net plate makers.liquid-canning machine.electric welding machine.film machinery.cloth .dry-cleaning .air cleaning etc.
Type |
Voltage (V) |
Current (A) |
Frequency (HZ) |
Max.air pressure (kPa) |
Max.flux (m³/h) |
Max.vacuum Degree(-kPa) |
Power |
Rotary speed r/min |
Noise dB(A) |
G.W. (kg) |
box up volumn (cm ) |
| GB-2200 | 220 |
8.52(10.22) 4.92(5.91) |
50(60) | 36(43) | 210(250) | 28(31) | 2.2(2.6) |
2800 (3400) |
<70 | 35.3 | 42*40*43 |
