Specifications
1)Less Energy Cost2)Structure Simple
3)Advanced technology
PVC floor tile making machine with price
Features and Application:
The series Extruders Coordinated with the appropriate moulds and auxiliary machines can directly convert thermoplastic expecialy PVC powder into Pipe,plate sheet,film and profile,and also completed function of plastic modifying and powder material pelleting.
The extruders drivd by D.C motor,SCR controlled stepless speed regulation.It equiped with the over-load protection and stoppage alarmingsystem,And loaded with the vacuum exhaust and force feeding machine.
Technical Parameter:
Parameter Model |
SJSZ-45 |
SJSZ-51 |
SJSZ-65 |
SJSZ-80 |
SJSZ-92 |
Diameter of screw(mm) |
45/90 |
51/105 |
65/132 |
80/156 |
92/188 |
Number of screw(mm) |
2 |
2 |
2 |
2 |
2 |
Direction of screws |
Screw rotation direction |
||||
Screw rotation speed(rpm) |
1-37 |
1-32 |
1-34.7 |
1-36.9 |
1-32.9 |
Effective length of screw(mm) |
985 |
1085 |
1450 |
1800 |
2500 |
Power of Main engine (kw) |
15 |
18.5 |
37 |
55 |
90 |
Barrel heating power (kw) |
12 |
18 |
24 |
36 |
86.8 |
Production capacity(kg/h) |
30-60 |
50-120 |
80-250 |
320-450 |
500-600 |
Center height(mm) |
1000 |
1000 |
1000 |
1000 |
1000 |
Net weight(kg) |
2800 |
3200 |
4000 |
5000 |
10000 |
Dimensions(mm)(L×W×H) |
3000×1050×2157 |
3620×1050×2200 |
4235×1520×2450 |
4750×1550×2460 |
6725×1550×2841 |
