Specifications
PVC WPC window frame machine1.long service life.
2.barrel cooling: air-blower.
3.water-proof,environment-friendly product
PVC WPC window frame machine
PVC WPC window/photo/mirror frame machine is optimized in design with reference to the newest technology.
The unit is composed of conical double-screw extruder, vacuum calibration table, hauling off machine, cutter, film sticking machine and material tumbling frame, etc.
The main machine adopts AC frequent variable drive system and the temperature control, both of which adopt high quality products.
The maintenance is simple and convenient.
The unit is also able to directly extrude artificial wood foamed profile material, and the effect is better than that of the single-screw extruder.
The plastic steel door and window profile production line adopts conical double-screw extruder, which processes PVC door and window profiles materials, plastic steel compound material, multiple-hole wire pipes, decoration profiles, etc.
Features:
- More durable,stable,hard density then wood fiber.
- Environmental friendly,100% recyclable,non-pollution,no toxic chemicals.
- Recoverable,recycle,classical environment protection materials.
- Against UV,weather resistance,flexible and strong arcing curves.
- Corrosion resistance,moisture resistance and resistant to hot.
- Colorful,easy to clean and maintenance.
.
Unit |
| YF210 | YF240 | YF500 | YF800 |
Extuder | Model | SJSZ-51 | SJSZ-65A | SJSZ-80 | SJSZ-92 |
Dimension(L*W*H) | 3300*1450*2100 | 3450*1450*2250 | 5000*1540*2280 | 6200*1550*2700 | |
Capacity(kg/h) | 50-150 | 80-250 | 100-360 | 200-600 | |
Total Power(kw) | 25 | 64 | 115 | 168 | |
Sizing case | Dimension(L*W*H) | 4200*1000*1100 | 6200*1000*1100 | 6500*1500*1100 | 6500*1650*1100 |
Total Power(kw) | 18 | 24 | 30 | 43 | |
Hauling machine&cutter | Dimension(L*W*H) | 5800*1000*1700 | 5800*1100*1700 | 3100*1300*1700 2200*1450*1800 | 3550*1850*1600 2500*1800*1600 |
Hauling Speed(m/min) | 0.1-4 | 0.1-4 | 0.1-3 | 0.1-2 | |
Hauling Traction(n) | 30000 | 30000 | 35000 | 50000 | |
Max.Cutting Section(L*W) | 180*65 | 240*65 | 500*80 | 800*80 | |
Total Power(kw) | 6 | 6 | 8 | 8 | |
Pipe length(m) | 6 | 6 | 6 | 6 | |
