Specifications
1.qingdao port2.take the excellent product,low price and good service
3.high output extuder
4. one year warranty
PVC Decoration Machine
PVC Sheet Machine. PVC Transparency sheet has many advantages, such as inflaming retarding, good equality and cheap price, high visible, smooth surface, little spots, impact resistance and formed easily, etc. It is widely used for package of fishing fittings, tools, toys, electron, foods, electronic products, medicament, clothings, etc.
PVC Sheet MachinePVC Sheet MachinePVC Sheet MachinePVC Sheet Machine
Features:
1) Extruder uses a screw stem with large L/D for a better forming effect
2) Screen tooli
Features:
1) Extruder uses a screw stem with large L/D for a better forming effect
2) Screen tooling part features advanced electrical hydraulic device to increase
efficiency
3) Tooling head has an inner-heater and can be easily adjusted
4) Even thickness and speed, energy-saving
5) Cutting machine adopts micro-computer-controlled hydraulic control that can cut
the film automatically
Max.output |
150kg/h |
Motor Power of baller |
3Kw |
Addition distance of felt wrapped roll |
0-20mm |
Extrusion machine |
4200×1600×2100 |
Dia of screw stem |
90mm-110mm |
Heating Power of drum |
16.5kw |
Fzce length of felt wrapped roll |
750mm |
Press-Polishing machine |
1100×1400×1900 |
Nataral scale |
30:1 |
Heating Power of drum |
6kw |
Number of felt wrappeil roll |
3 |
Electric control console |
900×400×1860 |
Width of die mouth |
730mm |
Heating Power of die head |
6.6kw |
Motor Power of extrusion machine |
30kw-45kw |
Baller |
1100×1400×1450 |
Thickmess of die mouth |
0.3-2mm |
water consumption |
1010m3/h |
Motor power of mash changer |
1.1kw |
Weight |
4.5t |
Dia of felt wrapped roll |
270mm-400mm |
Overall dimensions |
9.6×1.8×1.5Long×with×High |
Motor Power of Press-polishing machine |
3kw |
|
|
