Specifications
1.qingdao port2.take the excellent product,low price and good service
3.high output extuder
4. one year warranty
PVC plastic profile making machine
Exterior decorative plate machine mainly use plastic +power to extrude wood-plastic panel such as integral door panel, building template, cabinet door, window board, wainscot, etc. Proper double screw extruder and single screw extruder, specially used for wood plastic products,can be chosen in accordance with the panel section, application, product specific gravity. Also the corresponding auxiliary machines such as vacuum shaping platform,hauling machine, cross cutter, matrial reversing platform, etc. are equipped. Products of diversified specification can be produced with different dies. Hauling machine, designed by our company, holds features of stable working, high liability, strong hauling force. Adopting special oversize eddy current cooling system to reach cooling and shaping. The vacuum shaping in this line can satisfy extruding broad width wood-plasic panel. Cross cutter keeps synchronous operating with panel hauling.Thanks to reasonable design, the cutter runs stablely and holds auto size cutting.Also, the extrudion line equipped line is equipped with dust recyling device.
Max.output |
150kg/h |
Motor Power of baller |
3Kw |
Addition distance of felt wrapped roll |
0-20mm |
Extrusion machine |
4200×1600×2100 |
Dia of screw stem |
90mm-110mm |
Heating Power of drum |
16.5kw |
Fzce length of felt wrapped roll |
750mm |
Press-Polishing machine |
1100×1400×1900 |
Nataral scale |
30:1 |
Heating Power of drum |
6kw |
Number of felt wrappeil roll |
3 |
Electric control console |
900×400×1860 |
Width of die mouth |
730mm |
Heating Power of die head |
6.6kw |
Motor Power of extrusion machine |
30kw-45kw |
Baller |
1100×1400×1450 |
Thickmess of die mouth |
0.3-2mm |
water consumption |
1010m3/h |
Motor power of mash changer |
1.1kw |
Weight |
4.5t |
Dia of felt wrapped roll |
270mm-400mm |
Overall dimensions |
9.6×1.8×1.5Long×with×High |
Motor Power of Press-polishing machine |
3kw |
|
|
