Features
• Hydraulic cone crusher is a kind of crusher with unique characteristics produced by Xiamen Bestlink Factory Co.,Ltd.
• Compared with the ordinary spring cone crusher, this kind of hydraulic cone crusher uses the hydraulic cylinder as the safety device to replace the insurance spring.
• The hydraulic lock device is also used in the crusher equipment for the hydraulic adjustment discharging port.
• The left part of the hydraulic system is the hydraulic adjustment system, and the right part is a hydraulic insurance system.
Application
Hydraulic cone crusher is suitable for replacing spring cone crusher and common hydraulic cone crusher in the mining and construction industry.
It is broadly employed in metallurgical, layout, street constructing, and chemical marketplace.
Hydraulic cone crusher is suited to crushing hard and mid rocks and ores, like iron ores, copper ores, limestone, quartz, granite, gritstone, and so on.
Advantages
1. High crushing ratio and production efficiency.
2. Less spare part consumption and low operation cost.
3. Between-layer pressuring crushing and better finished product shape.
4. Hydraulic protection and hydraulic cavity clearing, high automatization and less stopping production and repairing time.
5. Fault-free operation ration surpass 85%
6. Easy to change the plate reduce the stoppage time
7. Hydraulic operation improve the service life
8. Laminated crushing principle reduce flaky product
9. Higher fine granularity quantity saved energy
Technical parameters of durable primary limestone quarry small spring cone crusher
| Specifications | Model | Cavity | Large end diameter of crushing cone(mm) | Adjusting range of discharge opening (mm) | Feed opening size of the open edge when recommending the Min.discharge opening(mm) | Max.Feeding size (mm) | Processing capacity (m³/h) | Main motor power (kw) | Weigh(kg) | Dimensions (L×W×H) (mm) |
| Φ900 | PYGD-0907 | Fine type | 950 | 8-25 | 70 | 60 | 80-220 | 160 | 17000 | 2007×2225×1950 |
| PYGD-0909 | Medium type | 10-25 | 90 | 76 | 90-220 | |||||
| PYGB-0921 | Coarse type | 22-38 | 210 | 178 | 155-250 | |||||
| Φ1100 | PYGD-1110 | Fine type | 1160 | 8-25 | 70 | 60 | 120-220 | 220 | 18500 | 2520×2620×2400 |
| PYGD-1112 | Medium type | 12-25 | 96 | 82 | 120-220 | |||||
| PYGB-1124 | Coarse type | 26-45 | 235 | 200 | 230-445 | |||||
| Φ1400 | PYGD-1411 | Fine type | 1400 | 8-25 | 80 | 68 | 115-370 | 315 | 29700 | 3106×3170×2945 |
| PYGD-1414 | Medium type | 10-25 | 106 | 90 | 140-370 | |||||
| PYGB-1433 | Coarse type | 26-50 | 330 | 115 | 300-620 | |||||
| Φ1500 | PYGD-1509 | Fine type | 1500 | 8-25 | 88 | 75 | 135-455 | 400 | 3800 | 3405×3480×3196 |
| PYGD-1512 | Medium type | 10-25 | 124 | 105 | 175-455 | |||||
| PYGB-1534 | Coarse type | 32-50 | 335 | 285 | 405-725 |
