Home > Manufacturing & Processing Machinery > Paper Machinery > Paper Making Machine > 1092mm High Speed Automatic Grade and New Condition Book Printing Machines for Sale
1092mm High Speed Automatic Grade and New Condition Book Printing Machines for Sale
US$ 350,000 - 450,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Product Type:
Other, Printing paper
Processing Type:
Other, paper making machine
Payment & Shipping
Payment Methods:
Port of Shipment:
Tianjin Qingdao Shanghai Ningbo
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Waste Paper and Cellulose Recycling Copying Paper Machine Wire TypeNegotiableMOQ: 1 Set -
1880mm Double Cylinder Double Wire Culture Paper A4 Paper Making MachineUS$ 250,000 - 300,000MOQ: 1 Set
-
787mm Double Cylinder Double Wire Culture Paper A4 Paper Making MachineUS$ 200,000 - 280,000MOQ: 1 Set
-
Printing Copy Paper Making Machine From Wood Pulp and Waste Old Book PaperUS$ 130,000 - 160,000MOQ: 1 Set
-
China Newspaper/culture Paper/writting/A4copy/print Paper Making Machine SuppliersNegotiableMOQ: 1 Set
Condition
New
Product Type
Other, Printing paper
Processing Type
Other, paper making machine
Place of Origin
Henan, China
Brand Name
Pingan
Model Number
1092mm
Voltage
can be specified
Power(W)
380V
Dimension(L*W*H)
According to each type
Weight
According to each type
Certification
Other, ISO9001:2008
Warranty
12 months
After-sales Service Provided
Engineers available to service machinery overseas
1092mm High Speed Automatic Grade and New Condition Book Printing Machines for Sale
Skype:hwasong03
Product Description
Technical Parameter
Output: Printing paper
Paper Weight: 15-200gsm
Net Paper Width: 1092mm
Cylinder Width: 1450mm
Design Speed: 150m/min
Working Speed: 60-100m/min
Capacity: 3-4T/D
Gauge: 1800mm
Pressure type: pneumatic pressure
Drive type: section drive with AC variable frequency
Machine design: square box type, right-side operation machine
Main Structure of Equipment
- Cylinder Part: 3pcs cylinder mold: φ1000mm×1450mm, 3pcs couch roll: φ380mm×1500mm, Rubber hardness: Shaw: 38±2°. 1pcs return roll: φ380mm×1500mm, rubber hardness: Shaw: 90±2°, equipped with 3sets cylinder vat.
- Press Part: 1pcs stone roll: φ450mm×1500mm, 1pcs rubber roll: φ400mm×1500mm, rubber hardness: Shaw: 90±2°, with pneumatic pressure device.
- Dryer Part: 2pcs cylinder dryer: φ1500mm×1450mm, 2pcs rubber roll: φ400mm×1500mm, rubber hardness: 90±2°, with pneumatic pressure device. Second dryer part sets dryer screens device for up and down.
- Press Polish Part: 1092mm three-roller press polish part
- Reeling Machine: 1092mm cylinder-type reeling machine
- Drive and Control Part: Apply section drive and AC frequency conversion with regulated speed and all-digital closed loop control system
Factory information:
Raw Material:
Certification:
Our Services
1. We will send technicians to installand test the machine for you.
2. We will train skilled workers for you.
3. We will supply best after-sale service.
Company Information
We have more than 30 years manufacturing experience of different kinds of paper machines in China. We strictly manufacture and manage according to IOS9001:2000 System and match all the CE standard or stricter standard. Our paper machine is running well in more than 20 countries. We are gold supplier on alibaba. Our guarantee period is 1 year. If there are any quality problems, We will help you at any time.
| FAQ: | ||||||||
| 1. What kind of paper machine your factory produce? | ||||||||
| We produce different kinds of paper machine. such as: | ||||||||
| a.Toilet Paper Machine which can produce toilet paper, tissue paper, napkin paper, handkerchief paper, towel paper and kitchen using paper etc. | ||||||||
| b.Culture paper machine which can produce A4 paper, notebook paper, copy paper, writing paper, printing paper and newsprinting paper etc. | ||||||||
| c.Packing paper machine which can produce kraft paper, fluting paper, corrugated paper, kraft liner paper, carton box paper and packing paper etc | ||||||||
| d.Coating paper machine which can produce coating paper, carbonless copy paper and thermal paper etc. | ||||||||
| 2. Can you make paper mill design for us? | ||||||||
| Yes, we have professional team with rich experience of paper mill design by CAD software. Our engineer will design paper machine suitable for your factory. You only need to tell us your open land dimension, we will make your future paper mill design. | ||||||||
| 3. How about your machine’s quality, we worry about the quality? | ||||||||
| We have more than 30 years manufacturing experience of different kinds of paper machines in China. We strictly manufacture and manage according to IOS9001:2000 System and match all the CE standard or stricter standard. Our paper machine is running well in more than 20 countries. We are gold supplier on alibaba. Our guarantee period is 1 year. If there are any quality problems, We will help you at any time. | ||||||||
| 4. What should I have to know if I want to get the quotation? | ||||||||
| 1.What kind of paper you want to produce(main important) | ||||||||
| 2.What kind of raw material you will use(main important) | ||||||||
| 3.The capacity you want produce per day(main important) | ||||||||
| 4.The paper weight you require. | ||||||||
| 5.The paper width you require. | ||||||||
| 5. Why your price is so high, is there any discount? | ||||||||
The price is matched with the quality of our machine. We can give you some discount if you want to buy our machine sincerely and earnestly. However, if you want a low quality paper machine. I tell you, we don’t produce. Our company’principle is client first, reputation premier. | ||||||||
| 6.Could your engineer can teach and train our workers and stay in our factory for long time? | ||||||||
| Yes, we have very large engineer installation team. They can train and teach your workers to operate paper machine, but you should pay them salary. | ||||||||
| 7.How long will it take to get the quotation? | ||||||||
| We usually give reply within 24hours after getting your inquiry. If you are urgent to get the quotation, please tell us by email, then we can reply you as the first priority. | ||||||||
| 8.How we visit your fatory and what will be the proedure? | ||||||||
| Our company located in Zhengzhou city, henan province, if you take plane, it will need about 2 hours from Guangzhou city, 1.5 hours from Shanghai city and 1 hour from Beijing city. We will pick you up from Zhengzhou airport or the train station. We will take you to see our machine running in our chinese clients' paper mill. Welcome you and your team to visit us at any time! |
