Hoozoe SImple Series- P10 SMD Full Color Rgb 3in1 P10 Full Color Led Module

Hoozoe SImple Series- P10 SMD Full Color Rgb 3in1 P10 Full Color Led Module thumbnail-1
Hoozoe SImple Series- P10 SMD Full Color Rgb 3in1 P10 Full Color Led Module photo-1
US$ 685 - 785 MOQ: 10 Square Meters
Key Specifications
Get Latest Price
Place of Origin:
Fujian, China
Brand Name:
Hoozoe
Model Number:
Hoozoe-Outdoor-SMD-P10-RGB
Contact Supplier Request Quote Chat Now
Fujian Hoozoe Optoelectronic Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
XIAMEN
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Fujian, China
Brand Name Hoozoe
Model Number Hoozoe-Outdoor-SMD-P10-RGB
Usage Indoor
Tube Chip Color Full Color
Display Function Other, Video,Message,Picture,Text
Pixels 10mm
Screen Dimension 960*960mm

Specifications

1.High Stability, Power Saving
2. Convenient assemble and save space
3. High Cost Performance
4. Ultrathin
5. CE, 3C etc.

Hoozoe SImple Series- P10 SMD full color rgb 3in1 p10 full color led module





P10 1/8 Scan Full Color Module of Indoor
Item Unit Parameter
Pixel Pitch mm 10.00
Pixel Density dots/sqm 10,000
Resolution of Module dots  32*16
Module Size mm 320*160
HUB   75
Led Package SMD3528
Pixel Configuration SMD3528 1R1G1B
Chip Brand of LEDs Silan/Epistar/Cree/Nichia
Module Weight kgs/pc 0.38KG
Brightness (White Balance) nits(cd/sq.m) 1500-1800
Red Wavelength nm 620-625
Green Wavelength nm 520-525
Blue Wavelength nm 470-475
Scan Mode  1/8 Scan
View Distance M 3--50
Best View Distance M 6--30
Viewing Angle-Horizontal deg. 120
Viewing Angle-Vertical deg. 120
Module Maximum Power W 25
Max. Power Consumption W/sq.m 500
Avg. Power Consumption W/sq.m 150
Working Voltage 5V 40A
Power Supply AC 110/220V
Waterproof Grade  IP24
Refresh Rate Hz/S 3,000
Frame Rate Hz/S ≥ 60
Gray Scale 4096 grades gray
Display Color 256*256*256
Display Function             Text,news,advertising,flash,animation
Input Signal RF,S-Video,RGB,RGBHV,YUV,YC,SDI,HD-SDI,DVI,UXGA,COMPOSITION,etc.
Luminance Degradation  Less than 5% after 1000 hours Ageing test, testing current 30mA, under normal temperature 25℃.
Defective Dot Rate   <0.0001
Life Span hours 100,000
MTBF hours >10,000
Storage Temperature ℃  -35 -- +80
Working Temperature ℃          -20 -- +60
Working Humidity                                     10-90%RH
Control System Synchronization or Asynchronization
Quality Certificate ETL,CE,RoHS,TUV,FCC class A,ISO9001:2008
Warrenty 2 Years
Working Environment Indoor
Other Fertures LED&ICs in Departed PCB
Note: The above parameter is just for reference. Changes can be made according to customers' requirements.



Hoozoe SImple Series- P10 SMD full color rgb 3in1 p10 full color led moduleOur Case

Hoozoe SImple Series- P10 SMD full color rgb 3in1 p10 full color led module



Reference Pictures



Hoozoe SImple Series- P10 SMD full color rgb 3in1 p10 full color led module

Hoozoe SImple Series- P10 SMD full color rgb 3in1 p10 full color led moduleHoozoe SImple Series- P10 SMD full color rgb 3in1 p10 full color led module

 Hoozoe SImple Series- P10 SMD full color rgb 3in1 p10 full color led module



Our Case



Hoozoe SImple Series- P10 SMD full color rgb 3in1 p10 full color led module





Connection Picture

Hoozoe SImple Series- P10 SMD full color rgb 3in1 p10 full color led module





Packaging & Shipping

 Hoozoe SImple Series- P10 SMD full color rgb 3in1 p10 full color led module









Our Services





(1). Product Quality :   For LED Modules , 24 hours Aging test before shippment;
                                           For LED Display, 72 hours Aging test  before shippment
                                           which will avoid some problems and make customers satisfied with
                                           the quality of our led products.
(2). After Sale Service : 1 year warranty ;
                                            Complete instruction for led screen installation
                                            Professional technical team for remote control maintenance .
