Hoozoe SImple Series- p10 outdoor full color p10 message board red

Name: Hoozoe SImple Series- p10 outdoor full color p10 message board red
Brand: Hoozoe
Price: USD $685 - 785 / Square Meter

FOB Price

USD $685 - $785 / Square Meter

10 Square Meters(Min.Order)

Product Details

Place of Origin:	Fujian, China	Brand Name:	Hoozoe	Model Number:	Hoozoe-Outdoor-SMD-P10-RGB
Usage:	Indoor	Tube Chip Color:	Full Color	Display Function:	Other, Video,Message,Picture,Text
Pixels:	10mm	Screen Dimension:	960*960mm

1.High Stability, Power Saving
2. Convenient assemble and save space
3. High Cost Performance
4. Ultrathin
5. CE, 3C etc.

P10 1/8 Scan Full Color Module of Indoor
Item	Unit	Parameter
Pixel Pitch	mm	10.00
Pixel Density	dots/sqm	10,000
Resolution of Module	dots	32*16
Module Size	mm	320*160
HUB		75
Led Package	SMD3528
Pixel Configuration	SMD3528 1R1G1B
Chip Brand of LEDs	Silan/Epistar/Cree/Nichia
Module Weight	kgs/pc	0.38KG
Brightness (White Balance)	nits(cd/sq.m)	1500-1800
Red Wavelength	nm	620-625
Green Wavelength	nm	520-525
Blue Wavelength	nm	470-475
Scan Mode	1/8 Scan
View Distance	M	3--50
Best View Distance	M	6--30
Viewing Angle-Horizontal	deg.	120
Viewing Angle-Vertical	deg.	120
Module Maximum Power	W	25
Max. Power Consumption	W/sq.m	500
Avg. Power Consumption	W/sq.m	150
Working Voltage	5V 40A
Power Supply	AC 110/220V
Waterproof Grade	IP24
Refresh Rate	Hz/S	3,000
Frame Rate	Hz/S	≥ 60
Gray Scale	4096 grades gray
Display Color	256256256
Display Function	Text,news,advertising,flash,animation
Input Signal	RF,S-Video,RGB,RGBHV,YUV,YC,SDI,HD-SDI,DVI,UXGA,COMPOSITION,etc.
Luminance Degradation	Less than 5% after 1000 hours Ageing test, testing current 30mA, under normal temperature 25℃.
Defective Dot Rate		<0.0001
Life Span	hours	100,000
MTBF	hours	>10,000
Storage Temperature	℃	-35 -- +80
Working Temperature	℃	-20 -- +60
Working Humidity	10-90%RH
Control System	Synchronization or Asynchronization
Quality Certificate	ETL,CE,RoHS,TUV,FCC class A,ISO9001:2008
Warrenty	2 Years
Working Environment	Indoor
Other Fertures	LED&ICs in Departed PCB
Note: The above parameter is just for reference. Changes can be made according to customers' requirements.

Our Case

Reference Pictures

Our Case

Connection Picture

Packaging & Shipping

Our Services

(1). Product Quality : For LED Modules , 24 hours Aging test before shippment;

For LED Display, 72 hours Aging test before shippment

which will avoid some problems and make customers satisfied with

the quality of our led products.

(2). After Sale Service : 1 year warranty ;

Complete instruction for led screen installation

Professional technical team for remote control maintenance .

Fujian Hoozoe Optoelectronic Co., Ltd.: Contact nameModern Dai; Phone0086-595-28765512; AddressNo.153, Chongxiang Rd., Qingmeng Zone Quanzhou,Fujian
