mechanical filter for wastewater treatment
Product Description: This product is suitable for applications requiring filtered water turbidity is generally 5 mg / l or less able to meet drinking water quality standards for industrial water or domestic water treatment equipment to industrial and mining enterprises and towns.
Single filter material is used for inlet water turbidity is about 100 mg/l , without the coagulation precipitate raw water.
Double filter material is use for inlet water turbidity is about 15-20 mg/liters of water of the precipitation.
Mechanical filters
Second, the main technical conditions and notes:
Working pressure 5kgf/cm2
Inlet water temperature ≥ 4 °C
Running speed 10m/min
Turbidity: water <20 mg / L water <5 mg / L
Mechanical filters, iron, and manganese filter, according to user requirements with a multi-way valve.
| model | CXJG-500 | CXJG-600 | CXJG-800 | CXJG-1000 | CXJG-1200 | CXJG-1500 | CXJG-1800 | CXJG-2000 | CXJG-2400 | CXJG-2600 | CXJG-3000 |
| diameter*high(mm) | 500*2700 | 600*3450 | 800*3450 | 1000*3450 | 1200*3550 | 1500*3550 | 1800*3750 | 2000*3750 | 2400*4000 | 2600*4100 | 3000*4450 |
| processing ability(t/h) | 2 | 3-4 | 5-7 | 8-12 | 12-15 | 18-26 | 25-38 | 31-47 | 45-68 | 53-79 | 70-106 |
