Home > Manufacturing & Processing Machinery > Plastic Machinery > Injection Molding Machine > Injection Molding Machine 1680KN for PET Bottle Preform With 8 - Cavity Injection Mold
Injection Molding Machine 1680KN for PET Bottle Preform With 8 - Cavity Injection Mold
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Type:
Preform Injection
Style:
Horizontal
Payment & Shipping
Payment Methods:
Port of Shipment:
NINGBO/SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Injection Molding Machine 3280KN for PET Bottle Preform With 32-cavity Injection MoldNegotiableMOQ: 1 Set -
2680KN Injection Molding Machine for PET Preform With 16 - Cavity Injection MoldNegotiableMOQ: 1 Set
-
2280KN Injection Molding Machine for PET Bottle Preform With 12 - Cavity Injection MoldNegotiableMOQ: 1 Set
-
Injection Molding Machine 3980KN for PET Bottle Preform With 32-cavity Injection MoldNegotiableMOQ: 1 Set
-
Injection Molding Machine 1380KN for Bottle Cap (PE) of Mineral Water BottleNegotiableMOQ: 1 Set
Condition
New
Type
Preform Injection
Style
Horizontal
Brand Name
OEM
Model Number
SAET-168PET
Place of Origin
Zhejiang, China
Plastic Type
Thermoplastic
Automatic
Yes
Injection Weight
520g
Injection Rate
175g/s
Clamping Force
1680KN
Opening Stroke
430MM
Power(W)
28KW
Certification
CE
After-sales Service Provided
Engineers available to service machinery overseas
Specifications
Injection Molding Machine for PET Bottle Preform with 8 - cavity injection mold , 900pcs/hourInjection Molding Machine 1680KN for PET Bottle Preform with 8 - cavity injection mold (900PCS/HOUR)
SPECIFICATION:
| SPECIFICATION | SAET-168PET | |
| INJECTION UNIT | ||
| Screw Diameter | mm | 50 |
| Screw L/D Ratio | L/D | 25 |
| Shot Size (Theoretical) | cm3 | 491 |
| Injection Weight(PET) | g | 520 |
| Injection Rate | g/s | 175 |
| Plasticizing Capacity | g/s | 30 |
| Injection Pressure | Mpa | 128 |
| Screw Speed | rpm | 0~150 |
| CLAMPING UNIT | ||
| Clamp Tonnage | kN | 1680 |
| Toggle Stroke | mm | 430 |
| Space Between Tie Bars | mm | 460x460 |
| Max. Mold Height | mm | 480 |
| Min. Mold Height | mm | 180 |
| Ejector Stroke | mm | 120 |
| Ejector Tonnage | kN | 40 |
| Ejector Number | Piece | 5 |
| OTHERS | ||
| Max. Pump Pressure | Mpa | 16 |
| Pump Motor Power | kW |
15 |
| Heater Power | kW |
13.00 |
| Machine Dimension(LxWxH) | m |
5.3x1.4x2.1 |
| Machine Weight | t |
5.2 |
| Hopper Capacity | L |
25 |
| Oil Tank Capacity | L |
250 |
