Specifications
Four heads laser cutter and engraving equipment1.CO2 laser tube
2.DSP control system
3.wide application
4.CE FDA
Four heads laser cutter and engraving equipment
Features:
1) 60w/80w/100w/130w/150w laser tube for your choice. Able to engrave and cut most non-metal materials.
2) Water cooling system (water pump / water chiller), cools and protects the laser tube.
3) Air pump, protects the material being engraved/cut from fire and helps to get better effect.
4) Exhaust fan and pipes, remove dust and smoke to protect optical parts and the user.
5) Aluminum blade table, holds hard sheet materials. Optional tables: honeycomb table, up/down lifting table.
6) Leetro USB controller system. Machine is able to work without connecting to a computer.
7)Imported lens and mirrors, brings high engraving and cutting precision.
8) Linear rails from Taiwan, more stable and precise.
9) English Lasercut 5.3 software.
10) Options: red dot, up/down lifting table, honeycomb table, rotary, etc.
Samples:
Technical parameter:
Model |
Laser engraving machine SK1280 |
Working area |
1200*800mm |
Laser tube power |
60w,80w,100w,130w,150w(can be optional) |
laser style |
Sealed CO2 laser tube, water-cooling, 10.6um |
Working life of tube |
1500hours |
Max Engraving speed |
0 - 60,000mm/min |
Cutting speed |
0- 30,000mm/min |
Location precison |
≤0.01mm |
Resetting positioning accuracy |
0.01mm |
Resolution ratio |
≤4000 dpi |
Laser tuber cooling |
Water cooling |
Power supply |
AC 110 - 220V , 50 - 60Hz |
Min. shaping character |
Chinese 2mm*2mm,English 1mm*1mm |
Supported graphic |
BMP, HPGL, PLT, DST, DXP, and AI |
Driving system |
Stepper motor |
360° slope engrave |
Yes |
Cooling system |
Water-cooling and protection system |
Operating system |
Windows98/7/2000/XP/VISTA/2007 |
Standard accessories |
(01)laser engraving cutting software --laser cut 5.3(English version) (02)User manual of machine(English version) (03) User manual of software (04)USB cable (05)communication cable (06) air exhaust fan (07)air pump (08)3 reflecting mirrors (has been installed in the machine) (9)one focus lens(has been installed in the machine ) (10)one laser tube(has been installed in the machine) (11) tool box that you need to repair or maintenance (12) USB port LED panel(has been installed in the machine) |
Optional parts |
(1) extra laser tube (2) motorized up and down platform (3) rotary attachment (4) red dot printer (5) industrial chiller cw5000 (6) auto focus (7) 3 layer filter (8) CCD camera (9) double laser head (10) auto feeding system |
Software supported |
CorelDraw, AutoCAD , Photo shop |
Operating temperature |
0°C~45°C |
Operating humidity |
5%~95% |
Gross power |
≤1500w |
Computer interface |
USB port and Standard printer port |
English manual |
Tell you how to run the laser machine and also the problems and solutions |
Spare parts:
Warranty terms:
1. 1 year for the whole machine
2. 3 months for laser tuber,lens and mirror
3. 6 months for equipments outfit, such as water pump, fan, air pump,ect
|
Laser cutting and engraving machine ----Jinan Suke Science &Technology Co., Ltd | |
Model |
Working area |
SK3030 |
300*300mm |
SK5030 |
500*300mm |
SK6040 |
600*400mm |
SK9060 |
900*600mm |
SK1280 |
1200*800mm |
SK1290 |
1200*900mm |
SK1490 |
1400*900mm |
SK1325 |
1300*2500mm |
SK1525 |
1500*2500mm |
SK1630 |
1600*3000mm |
SK9060(Separable) |
900*600mm |
SK1060(Separable) |
1000*600mm |
SK1280(Separable) |
1200*800mm |
SK1290(Separable) |
1200*900mm |
SK1610(Auto Feeding) |
1600*1000mm |
SK1325(Auto Feeding) |
1300*2500mm |
SK1625(Auto Feeding) |
1600*2500mm |
We can also make the machine as your customized size. | |
We also have other size machines,your customized machines are available!
If you have any question,please feel free to contact with me,I'll reply asap,your enquiry is much appreciated! skype:sukelaser3
