PA system 40W Desktop Power Echo Mixer Amplifier
Product Description
It’s mixing amplifier with preamp. The rated power is from 20W to 120W which meet the demand of medium scale PA system. It’s with 2 modes of power output in order to be connected with constant voltage speaker and constant impedance speaker. They’re constant voltage output at 100V or 70V and constant impedance output at 4 to 16 ohm with 6 level indicators. Complete protection circuit is for over-heat, overload, short, etc. What’s more, it’s with excellent fan which is high efficiency and quiet when operating.
Features
- Rated Power: 20W, 40W
- With 1 Mic 2 input (5mV 1 Kohm) and 1 AUX input (350mV 10 Kohm)
- 1 balanced/unbalanced Mic 1 input (2.5/5mV 1/2 Kohm)
- 1 TEL input (Sensitivity is 350mV 2 Kohm)
- With internal tone control (Bass: ±10dB at 100Hz; Treble: ±10dB at 10KHz)
- Priority from high to low: TEL>Mic 1>Mic 2 & AUX
- With complete protection circuit for short, overload, over-heat, etc.
- 2 modes of power output: constant voltage output at 100V or 70V; constant impedance output at 4 to 16 ohm
Specification
| Model | T-20AP | T-40AP |
| Rated Power | 20W | 40W |
| Max. Rated Power | 30W | 60W |
| Speaker Output | 4 to 16 ohm, 70V/100V | |
| Sensitivity/Impedance of Input | 350mV/50 Kohm | |
| S/N Ratio | Less than 90dB | |
| Frequency Response | 50Hz to 18 KHz | |
| Input of Mic 1/2 | Mic 1/2 input at 5mV, Front output at 1V | |
| Sensitivity/Impedance of Input | 5mV/600 ohm | |
| S/N Ratio | Less than 62dB | |
| Tone Control (Bass: 100Hz, Treble: 10KHz) | ±12dB | |
| Voltage of Phantom Power | DC +48V | |
| AUX 1 Input | ||
| Sensitivity/Impedance of Input | 350mV/15Kohm | |
| S/N Ratio | Less than 76dB | |
| Frequency Response | 50Hz to 18KHz | |
| <-3dB | ||
| Tone Control (Bass: 100Hz, Treble: 10KHz) | ±12dB | |
| Front Output | 1V/600 ohm | |
| T.H.D. | 1V/600 ohm | |
| Line Output | 10dB/3Kohm | |
| Power Supply | AC 110V of 60Hz or AC 230V of 50Hz or DC 24V | |
| Power Consumption | 45W | 75W |
| Dimension | 276*245*70mm | |
| NG | 4Kg | 4.5Kg |
