TROPICAL BLISTER PACKAGING MACHINE

Name: TROPICAL BLISTER PACKAGING MACHINE
Brand: HUALE MACHINERY
SKU: 127997235

US$ 1 - 100,000 MOQ: 1 Set

Key Specifications

Condition:

New

Application:

Chemical, Commodity, Food, Other, Medical, Other, Chemical, Commodity, Food, Machinery & Hardware, Medical, Other

Automatic Grade:

Automatic

Nanjing Huale Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Application Chemical, Commodity, Food, Other, Medical, Other, Chemical, Commodity, Food, Machinery & Hardware, Medical, Other

Automatic Grade Automatic

Driven Type Electric

Voltage 380V/220V

Power 11.5kw

Place of Origin Jiangsu, China

Brand Name HUALE MACHINERY

Model Number DPP-160/250F

Dimension(L*W*H) 4450*800*1600mm

Weight 1700KG

Certification CE, ISO9001

Warranty ONE YEAR

After-sales Service Provided Engineers available to service machinery overseas

Product Name: TROPICAL BLISTER PACKAGING MACHINE

MAIN TECHNICAL PARAMETERS

Item Model		DPP-160F
Double Function		ALU-PLASTIC-ALU	ALU-PLASTIC
Cutting frequency (ideal size 57×80)		15-30times/min	20-45times/min
Max. Forming Area and Depth(mm)		150×110×15	150×110×15
Pulling Length (mm)		30-120mm
Packaging material(I.D.Φ75)	PVC(mm)	(0.15~0.4)×160×(Φ350)	(0.15~0.4)×160×(Φ350)
	PTP(mm)	(0.02~0.15)×160×(Φ250)	(0.02~0.15)×160×(Φ250)
	Tropical Foil(mm)	(0.10-0.12)×160×(Φ350)
	Paper(mm)		(50-100)g/m2×160×(Φ300)
Power		380V 50Hz 11.5kw	380V 50Hz 8.5kw
Air compression(self-prepared)		≥0.5m³/min pressure:0.6~0.8Mpa
Cooling		Recycle water or circulating water consumption: 60-100L/h
Overall Dimension(LWH)		3660×700×1500(Including foundation)
Dimension of Each Part		1200×700×1500mm(front)
		1460×700×1400mm(middle)
		1000×700×1400mm(back)
Weight		About 1200kg

Item Model		DPP-250F
Double Function		ALU-PLASTIC-ALU	ALU-PLASTIC
Cutting frequency (ideal size 57×80)		15-30times/min	20-45times/min
Max. Forming Area and Depth(mm)		250×120×15	250×120×15
Pulling length(mm)		30-120mm
Packaging material(I.D.Φ75)	PVC(mm)	(0.15~0.4)×260×(Φ400)	(0.15~0.4)×260×(Φ400)
	PTP(mm)	(0.02~0.15)×260×(Φ250)	(0.02~0.15)×260×(Φ250)
	Tropical Foil(mm)	(0.10-0.12)×260×(Φ400)
	Paper(mm)		(50-100)g/m2×260×(Φ300)
Power		380V 50Hz 11.5kw	380V 50Hz 8.5kw
Air compression(self-prepared)		≥0.5m³/min pressure:0.6~0.8Mpa
Cooling		Recycle water or circulating water consumption: 60-100L/h
Overall Dimension(LWH)		4450×800×1600(Including foundation)
Dimension of Each Part		1400×800×1600mm(front)
		1650×800×1450mm(middle)
		1400×800×1450mm(back)
Weight		About 1700kg

MACHINE ADVANTAGE

Pulling length can be input by touch screen while air frothing forming and cold forming are controlled by encoder.
It comes with universal feeder for packaging object feeding; the feeder also can be designed as client’s requirement to irregular shape object.
The speed is controlled by inverter which operators can input by touch screen.
The machine comes with Automatic Detection system for object absence in blisters by mechanical detecting system or optical sensor or camera system is required by clients.
The pulling is controlled by servo motor for ensuring accurate pulling length and saving materials.
The heating molds separate automatically when the machine stops, which contributes to protect the packaging material from the heated moulds.
The machine suitable for blister packing with Alu-Plastic,Alu-Aluand Alu-Plastic-Alu.
