Advantages of centrifuge machine:
1, Little space and easy operation
2, Low noises
3,The tubular centrifuge machine extremely convenient to maintain
Introduction of GF series tubular centrifuge machine:
The high speed tubular centrifuge machine is the equipment that works with high separation factor and
capacity, GF tubular centrifuge machine is used for separating various liquids that are difficult for
separation,especially adapt for liquid-liquid separation, liquid-liquid-solid separation, liquid-solid separation.
Working principles of tubular centrifuge machine:
When the tubular centrifuge machine works, the motor passes the dynamic force to the driven wheel through driving strap and tension pulley, thus for the bowl to rotate around its own axis at high speed, forming a strong centrifugal force field. The material is injected inside from the liquid inlet on the bottom.
The centrifugal force compels the material liquid to flow upwards along the inner wall of bowl, and the liquid phase of large density is formed into outer ring and the liquid phase of small density is shaped into inner ring,to flow to the top of bowl, to be discharged out from their respective liquid outlets.The micro solids settle on the wall of the bowl and are to be manually discharged after the machine is shut down.
(As the pictures)
Application of tubular centrifuge machine:
Mainly used for the separation of various difficult separation of the emulsion, particularly applicable to a little difference in density of the liquid two-phase, liquid separation (difference in specific gravity is greater than 0.1%), and containing a small amount of impurities in the liquid, liquid and solid separation.
Oil separation,transformer oil, edible oil dehydration and dewaxing, turbine oil, biodiesel, coal tar, lubricating oil, marine fuel oil, quenching oil; various syrups separation; separation of whole blood-from whole blood to separate plasma and blood cells; separation of biological products; oil-water separator, sewage treatment.
Model |
GF/GQ80 |
GF/GQ105 |
GF/GQ125 |
GF/GQ150 |
|
|
Drum |
ID(mm) |
75 |
105 |
125 |
147 |
Height (mm) |
450 |
730 |
730 |
730 |
|
Sedimentation volume(L) |
2.67 |
6 |
8 |
10 |
|
Max speed(r/min) |
21000 |
19000 |
17500 |
16000 |
|
Max separation factor |
22500 |
21000 |
21000 |
21000 |
|
Inlet nozzle diameter (mm) |
3/4/6 |
4/6/8 |
6/8/10 |
8/10/12 |
|
Material inlet pressure (Mpa) |
≥0.05 |
||||
Capacity (water capacity)L/H |
260 |
1600 |
2200 |
3200 |
|
Actually Capacity L/H(according to the solid content) |
50-80 |
300-500 |
500-700 |
800-1000 |
|
Motor model |
3 phase two pole motor |
||||
Motor power (kw) |
1.5 |
2.2 |
3 |
3 |
|
Machine dimension (mm) |
500*700*1300 |
600*1000*1600 |
600*1000*1600 |
600*1000*1600 |
|
Machine weight (kg) |
300 |
460 |
490 |
510 |
|
