Functions & Features
- Convenient and classified concentration of solid substance produced in the procedure
of food or pharmaceutical production, the environmental treatment, the bio (microbe, botany, animal)
culture procedure
- Gold metallic painting of main body for the appropriate confrontation to the critical change
of ambience and shock proof
- Concentration of sound quality in the shape of solid
- Opening of whole surface and easy loading and unloading
- Strengthened safety with 2 door-locks
- Part of connection of spindle and the upper body of the bowl is the unified screw cover
with easy handling to protect operator and spindle
- Control box of convenient handling and central processing
- Inspection apparatus checking purity of separated liquid
- LCD touch screen displaying rpm, rcf, time is suitable for treating bacteria and yeast
- Solid substance is collected on Teflon sheet
- Specially designed triangular impeller
- Function of dispensing substance and of fixing Teflon sheet to the inner wall of bowl
- Low vibration and the compact size for easy installation in tiny space
Applications
1. Pharmaceuticals: medicine intermediate, herb medicine extracts, medicinal plant fiber, chlorella
2. Dyeing waste :
- Dyeing waste water, leather waste, oil tank solids, oil (lubricants, machinery, cleansing oil) recycling,
chemical industries
- Ink, various paints, ammonia heritage, barium vitriol, aluminum oxide, activated carbon, zinc vitriol, dye
3. Food : Peanut oil, rapeseed oil, grain starch, animal/plant oil refining, cereal flour, gelatin, amino acids,
soy sauce, skim milk
4. Others : Whole separation and refining in dairy process, cosmetics manufacturing, the manufacture of liver oil,
yeast manufacturing, bio-technology areas, such as clean separation of the liquid and used for collection of solid water.
|
Item Model
Item |
GQ150 |
|
|
Drum |
ID(mm) |
147 |
Height (mm) |
730 |
|
Sedimentation volume(L) |
10 |
|
Max speed(r/min) |
16000 |
|
Max separation factor |
21000 |
|
Inlet nozzle diameter (mm) |
8/10/12 |
|
Material inlet pressure (Mpa) |
≥0.05 |
|
Capacity (water capacity)L/H |
3200 |
|
Actually Capacity L/Haccording to the solid content) |
500-700 |
|
Motor model |
3 phase two pole motor |
|
Motor power (kw) |
3 |
|
Machine dimension (mm) |
600*1000*1600 |
|
Machine weight (kg) |
490 |
|
Washing car:
solid in the drum
separaton result compare:
package and transportation:
