The GQ105 high speed tubular centrifuge designed with a round which is either painted or made of stainless steel through the one piece casting process,the internal spare parts contacting with materials are all constructed from 304 stainless steel. Technical parameters: Model Separation factor ID of bowl(mm) Bowl length(mm) Bowl volume(L) Rotation speed(RPM) Production capacity(L/H) Motor power(KW) Dimensions (L*W*H) (mm) GQ105 18000 105 730 6 16500 1200 2.2 500*600*1650 This product is a kind of solid-liquid separator with high separation factors.It is applicable to separate liquid and solid mediums characterized by low concentration ,small particles,high viscosity coupled with small specific gravity differences,The high speed tubular centrifuge is primarily ideal for the suspensions which are hard to be separated and possess small solid content.So far it ha been broadly employed for biological product,chemical products ,beverage as well as other industries.This instrument can also be commonly seen in schools,laboratories,research institutes etc. We are a professional high speed tubular centrifuge manufacturer and supplier in China .We also provide 2 phase separation horizontal decanter centrifuge,sludge feeding system,high speed refrigerated centrifuge,refrigerated centrifuge,and much more.
Model |
Separation factor |
ID of bowl(mm) |
Bowl length(mm) |
Bowl volume(L) |
Rotation speed(RPM) |
Production capacity(L/H) |
Motor power(KW) |
Dimensions (L*W*H) (mm) |
GQ105 |
18000 |
105 |
730 |
6 |
16500 |
1200 |
2.2 |
500*600*1650 |
