Single Phase Power Factor Meter / Watt Meter

Name: Single Phase Power Factor Meter / Watt Meter
Brand: SOMMY
SKU: 127939743
Availability: InStock

US$ 22 - 26 MOQ: 2 Pieces

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

SOMMY

Model Number:

EP8W-RC18B

Zhongshan Sommy Automation Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Zhongshan/Guangzhou/Shenzhen/Hongkong/Ningbo/Zhuhai/Qingdao/Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name SOMMY

Model Number EP8W-RC18B

Measuring Current Range directly input AC 0.015~5A, support CT

Measuring Voltage Range directly input AC6~450V

Accuracy Class 0.5%

Operating Temperature -10~50

Dimensions 48H*96Wmm

Single Phase Power Factor Meter / Watt Meter

Product Description

Features:

1.Measure and display power factor and active power

2. Accuracy:0.5%F.S

3. With 2 programable alarms relay output

4. Optional 4-20mA transmition output .

5. With RS485 communication port ,modbus RTU

6. Support CT(current transformer), can set the CT ratio freely on the menu of the meter

Technical specification:

Directly input range	voltage:AC6-450V current:AC0.015-5A	Power supply	AC/DC 100-240V
Directly input range	voltage:AC6-450V current:AC0.015-5A	Dielectric strength	AC 1500V/1min
CT	Setting range:1.0-1999	Sampling speed	2 times/Second
Measuring accuracy	0.5%F.S	Insulated impedance	100MΩ
Working environment	-10~50 degree relative humidity<=85%RH
Input impedance	voltage input impedance.=300kΩ(600V);current input impedance<=0.02Ω(when input 0-5A)
