1000l Micro Beer Brewery Equipment for Fresh Cerveza

Our company is a private enterprise integrating with R&D, processing and engineering installation which is specialized in manufacturing of beer brewing equipment.

• Available with polished stainless steel brewhouse vessels
• Available with steam heating
• Modular brewhouse design, available either in a 2-Vessel version (brewkettle/whirlpool and mash/lauter tun, shown above), or 4-Vessel version with separate brewkettle, whirlpool, mash tun and lauter tun.
• Optional hot and cold liquor tanks are also available

                                                           Brewing is typically divided into 9 steps: milling, malting, mashing, lautering, boiling, fermenting conditioning, filtering, and filling.

The mashing-lautering-boiling-whirlpool take place in the brewhosue, turn the malt into wort.

In order to provide the one-stop service, we could help you purchase the yeast, hops and other related raw materials for you.

Note: 1hl=100liter; 1Gallon=3.7854liter; 1Barrel (BBL) =117Liter;

 *Mash/Lauter tank:

 Double walled with insulation layer

Equip with agitator

Grist case for large capacity tank(optional) 

Milled false bottom 

Side door for spent grains (automatic device for large capacity optional) 

Raker with variable speep drive  

Recirculation with sight glass 

Ring of sparging 

Buffer/grant&Wort collection outlets (optional)

 *Kettle/whirlpool tank:  

Double walled with insulation layer 

Equip with agitator 

Heating elements/heating jacket, depend on heating method adopt  

Optional:

3-vessel: mash tun-lauter tank-kettle/whirlpool tank

               mash/kettle tank-lauter tank-whirlpool tank(combination  type optional)

4-vessel: mash tun-lauter tank-kettle-whirlpool tank

Hot water tank, Screw conveyer, Grist case optional

Process: mirro polishing, pure argon gas protecting welding, double face forming

Panel: Mirro/wire-drawing/2B optional

1.Inner are of international standards of quality 304 stainless steel material, high-pressure polyurethane foam insulation, the jacket in accordance with customer requirements, can be polished stainless steel, matt, carbon steel, the form of spraying.

2.The application of international standardized fermented beer production technology, a wide range of temperature control application technology, mirror polishing inside the tank, up to ≤0.8u≤0.6um≤0.2um polishing quality standards, fully meet the PLC automatic cleaning and disinfection of the controlled system requirements.

3.Fermentor cooling jacket at the same time meet the needs of the country the world’s technical standards, the provision of Maitreya paneles, arched passages spinulosa Watt Jacket channel heat exchangers and other methods to meet different cooling media and the pressure of the heat exchange technology needs.

Material: stainless steel AISI 304

thickness: 3mm

Inner surface treatment: cold-rolled plates , 2B surface treatment, welds grinded to Ra 0,8µm.

External surface treatment: cold-rolled plates grinded to SBCooling:

Cylinder: 3 cooling-sections

Conical bottom : 1 cooling-section
Working pressure in cooling-sections - 1,5 bar

Insulation: Polyurethane - thickness 150 mm, density 1,09 g/cm³:both cylinder and conical bottom

External-Jacket:  Stainless steel plate - thickness 1,5 mm, both cylinder and conical bottom

Working pressure: 1,5 bar in cylindrical-part (filled-up tank, at 20°C)

Complete beer brewery equipment description:

We can supply 50L,100L, 200L, 300L, 500L, 1000L ,2000L,3000L,5000L,10000L and so on capacity beer machinery.

Tell me your specifications and I will customize for you acccording to your requirements.

Our equipment is well designed by professional designer, and adjustable according to your request. The best material is used to product your machine. The equipment is carefully packed before delivering.

1. LCL/FCL(20GP/40GP/40HQ)
2. packed with plastic film in fumigation free wooden case or fixed with iron frame
3. up to export standard, suitable for delivery
4. customer's requirements available

We ensure every order will not live up to the customers' requirement. Every order will be check by the professional skilled engineer before shipping.

We Serve:

-Customized capacity&configurations proposal list
-CAD/3D layout drawings
-Technical drawings of the equipment
-Engineer going abroad for installation, debugging and technical training
-Main guarantee for three years, life long service
