Rubber Sheathed Flexible Welding Cable

Name: Rubber Sheathed Flexible Welding Cable
Brand: Sanhe
SKU: 127860067

US$ 600 - 1,500 MOQ: 2000 Meters

Key Specifications

Place of Origin:

Henan, China

Brand Name:

Sanhe

Model Number:

16mm2----95mm2

Zhengzhou Sanhe Cable Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao or Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Henan, China

Brand Name Sanhe

Model Number 16mm2----95mm2

Insulation Material Rubber

Type Low Voltage

Application Other, welding machine

Conductor Material Copper

Jacket Rubber

Rubber sheathed flexible Welding Cable

1th. Service Conditions

This product is suitable for the welding machine whose voltage to the ground is not more than 200V and pulsating current value is 400V.

2th. Model, Names Main applications and Work In the Temperature

Model	Name	Main applications	Working temperature of core ≤⁰C
60245-81(YH)	Natural Rubber Sheath for Welding Cable	Always used indoor	65
60245-82(YHF)	Neoprene Rubber Sheath Welding Cable	Always used outdoor	65
60245-82(YHF)	Synthetic elastomer Sheath Welding Cable	Always used outdoor	65

3th. Standards: IEC60245

4th. Specifications, Size, Technical Data

Conductor Nominal Section (mm2)	Conductive Core	Average Outer Diameter (mm)		20oC Conductor Resistance≤(Ω/km)
Conductor Nominal Section (mm2)	Number/Diameter of Core(mm)	Min	Max	20oC Conductor Resistance≤(Ω/km)
16	513/0.20	9.2	11.5	1.16
25	798/0.20	10.5	13.0	0.758
35	1121/0.20	11.5	14.5	0.536
50	1596/0.20	13.5	17.0	0.379
70	2214/0.20	15.0	19.5	0.268
95	2997/0.20	17.0	22.0	0.198
