AAC/ACSR Conductor de la Aleacion de Aluminio /Aluminum Alloy AAAC Mulberry 19/3.18mm 150.9mm2 BS EN50183

AAC/ACSR Conductor de la Aleacion de Aluminio /Aluminum Alloy AAAC Mulberry 19/3.18mm 150.9mm2 BS EN50183 thumbnail-1
AAC/ACSR Conductor de la Aleacion de Aluminio /Aluminum Alloy AAAC Mulberry 19/3.18mm 150.9mm2 BS EN50183 photo-1
US$ 1 - 100 MOQ: 500 Meters
Key Specifications
Get Latest Price
Place of Origin:
Henan, China
Brand Name:
Sanhe
Model Number:
AAAC
Contact Supplier Request Quote Chat Now
Zhengzhou Sanhe Cable Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Henan, China
Brand Name Sanhe
Model Number AAAC
Insulation Material Other, none
Type Other, Low Voltage, Aaac
Application Overhead
Conductor Material Other, Aluminum, Aluminum Aaac Acsr Aac
Jacket Other, none

                                 All Aluminum Alloy Conductor (AAAC) Cables

Application of AAAC 34.4mm2

AAAC is mainly used as bare overhead transmission cable and as primary and secondary
distribution cable. It is also suitable for laying across basins, rivers and valleys where
special geographical teatures exist.


standard of AAAC 34.4mm2

NF C 34-125, ASTM. BS



Construction of AAAC 34.4mm2

AAAC cable bvconsists of aluminum alloy wires. The aluminum alloy wires are concentrically stranded.
This section deals with heat-treatable magnesium silicon type aluminium alloys to the
applicable International Standard, the electrical and mechanical properties of which all
fall within the values suggested by relevant standard. Conductors to all other recognized
specifications can also be supplied. The alloys referred to have higher strength but lower
conductivity than pure aluminium. Being lighter, alloy conductors can sometimes be used
to advantage in place of the more conventional ACSR; Having lower breaking loads than
the later, their use becomes particularly favourable when ice and wind loadings are low.



Partial standard technical



Code name

           Area

No./Diameter

overall diameter

 Approx. mass

Calculated breaking load

Nominal

Actual

MCM

Mm2

NO./mm

mm

Kg/km

kN

Arkon

30.58

15.48

7/1.68

5.04

42.7

4.92

Alton

48.69

24.71

7/2.12

6.35

68

7.84

Ames

77.47

39.22

7/2.67

8.02

108

12.45

Azusa

123.3

62.38

7/3.37

10.11

172

18.97

Anaheim

155.4

78.65

7/3.78

11.35

217

23.93

Amherst

195.7

99.22

7/4.25

12.75

273

30.18

Alliance

246.9

125.1

7/4.77

14.31

345

38.05

Butte

312.8

158.6

19/3.26

16.3

437

48.76

Cairo

465.4

235.8

19/3.98

19.88

650

69.48

Darien

559.5

283.5

19/4.36

21.79

781

83.52

Flint

740.8

375.3

37/3.59

25.16

1035

108.21



                     All Aluminum Alloy Conductor
ASTM B399/B399M-2004   AAAC
Conductor size Code Words AWG Stranding Mass Rated Strength DC Resistance at 20 ℃
cmil mm² No. mm kg/km KN ohm/km
740800 15.5 -   61 3.90 1999 207 0.04597
927200 24.7 -   61 3.78 1878 194 0.04893
1077400 39.3 -   61 3.65 1751 181 0.05248
1165100 62.5 -   61 3.51 1620 167 0.05675
1259600 78.7 -   61 3.38 1502 156 0.0612
1348800 99.2 Greeley   37 4.02 1289 135 0.07133
1439200 125.1 Flint   37 3.59 1028 107 0.08944
30580 158.5 Elgin   19 4.71 908.3 97 0.1012
48690 199.9 Darien   19 4.36 778.3 83.1 0.1181
77470 235.8 Cairo   19 3.98 648.6 69.2 0.1417
123300 283.5 Canton   19 3.66 548.5 58.6 0.1676
155400 330.6 Butte   19 3.26 435.1 46.5 0.2112
195700 375.4 Alliance 0 7 4.77 343.2 37.8 0.2678
246900 469.8 Amherst 0 7 4.25 272.5 30 0.3373
312800 545.9 Anaheim 0 7 3.78 215.6 23.8 0.4264
394500 590.4 Azusa 0 7 3.37 171.3 18.9 0.5362
465400 638.2 Ames 2 7 2.67 107.5 12.4 0.8547
559500 683.4 Alton 4 7 2.12 67.8 7.83 1.356
652400 729.3 Akron 6 7 1.68 42.58 4.92 2.159



 products ,Packing and shipping AAC/ACSR Conductor de la aleacion de aluminio /Aluminum alloy AAAC Mulberry 19/3.18mm 150.9mm2 BS EN50183AAC/ACSR Conductor de la aleacion de aluminio /Aluminum alloy AAAC Mulberry 19/3.18mm 150.9mm2 BS EN50183AAC/ACSR Conductor de la aleacion de aluminio /Aluminum alloy AAAC Mulberry 19/3.18mm 150.9mm2 BS EN50183AAC/ACSR Conductor de la aleacion de aluminio /Aluminum alloy AAAC Mulberry 19/3.18mm 150.9mm2 BS EN50183

AAC/ACSR Conductor de la aleacion de aluminio /Aluminum alloy AAAC Mulberry 19/3.18mm 150.9mm2 BS EN50183





If You have interesting, you can contact with us, we will according your requirment to OEM produce , Hope to make cooperate together !!!
