Solvent Laminating Machine

Solvent Laminating Machine thumbnail-1
Solvent Laminating Machine photo-1
US$ 10,000 - 50,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Zhejiang, China
Brand Name:
guotai
Contact Supplier Request Quote Chat Now
Ruian Guotai Plastic Machine Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
NINGBO
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Place of Origin Zhejiang, China
Brand Name guotai
Model Number BGF
Usage Other, LAMIANTING MACHINE
Automatic Grade Automatic

Specifications

Application:
This machine is suitable for laminating plastic-plastic.paper-plastic,paper-paper and aluminum foils and other lam

Principle picture


Application:
This machine is suitable for laminating plastic-plastic.paper-plastic,paper-paper and aluminum foils and other laminatd materials in the packing industry.

Main technical variables:


Type GF-800D GF-1000D GF-1200D

Max.LaminatingWidth 800mm 1000mm 1200mm

Max.Web Width 850mm 1050mm 1250mm

Max.LaminatingSpeed 150m/min 150m/min 150m/min

Max.MechanicalSpeed 160m/min 160m/min 160m/min

Max.DiameteroMaterialRoll 600mm 600mm 600mm

InternalDiameter of Roll Core 76mm 76mm 76mm
LengthofDrying Channel 10000mm 10000mm 10000mm

PowerforDrying Channel 72kw 84kw 92kw
TotalPower 128kw 140kw 154kw

WeightoMachine 10000kg 11000kg 12000kg

OverallDimensionL×W×H L12500×W4000×H3200mm L12500×W4200×H3200mm L12500×W4400×H3200mm


Performance and Features:
1.Whole machine controlled by PLC controller, with high running reliability and stability.
2.In-touch screen man-machine interface,10.4"
3.Imported nine vector motor closed loop auto-tension synchronous control systen.
4.Anilox roller with doctor blade for coating,various of anilox rollers available for different coating amount.
5.Turret type unwinding station with EPC and auto splicing system,high speed non-stop shaft exchange
6.Turret type rewinding station with EPC and auto splicing system pre-driver,high speed non-stop shaft exchange
7.Movable doctor blade with pneumatic back pressure
8.Four independent constant temperature section drying system with separated heating station and hot air in feeding.Temperature is controlled automatically.
9.Pneumatic lifting drying channel and operating platform for web passing,active synchronous running leading roller inside drying channel
10.Pre-heating before laminating, water cooling roller for laminated web.
11.Inflatable Air Shaft for web loading/unloading
12.Three rollers nip laminating method,laminating pressure more even to ensure higher peel strength
