1550nm Erbium Doped Fiber Amplifier (Super Low Input)

1550nm Erbium Doped Fiber Amplifier (Super Low Input) photo-1
1550nm Erbium Doped Fiber Amplifier (Super Low Input) photo-2
1550nm Erbium Doped Fiber Amplifier (Super Low Input) photo-3
1550nm Erbium Doped Fiber Amplifier (Super Low Input) photo-4
1550nm Erbium Doped Fiber Amplifier (Super Low Input) photo-5
1550nm Erbium Doped Fiber Amplifier (Super Low Input) photo-6
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
Eric
Model Number:
1550nm
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai /ningbo /shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Zhejiang, China
Brand Name Eric
Model Number 1550nm

Specifications

1:1550nm EDFA optical amplifier
2:13~27dBm output power
3:SNMP optional
4:Two power supply optional
5:Multi-output ports

1.0 Features

1. With the extension of network and the development of ring network, it is necessary to use DCM to compensate the dispersion, but because the insert loss of DCM reaches 4 ~ 8dBm. The input of EDFA will become low and C/N will be down. The model of EDFA can solve this problem.
2. Dual mechanic cooler in the housing and inside iron box to protect the laser. Work a long time.
3. RJ45 port for SNMP remote management.
4. RS232 for local management.
5. Adopts JDSU, Fitel and Bookham Pump laser.
6. Good stability, VFD or LED displays the working conditions, good trouble alarm system.
7. Power supply 90V ~ 265V AC or -48V DC for the user’s choice.
8. Max output can reach 27dBm.

2.0 Parameters

Items

Parameter

1550
        -14

1550
        -15

1550
        -16

1550
        -17

1550
        -18

1550
        -19

1550
        -20

1550
        -21

1550-
        22 ~ 27

Output(dBm)

14

15

16

17

18

19

20

21

22 ~ 27

Output(mW)

25

32

40

50

63

80

100

125

160~500

Input(dBm)

-9 ~ 10

Wavelength(nm)

1530 ~ 1565

Output Power Stability

<±0.2dB

Bias Oscillation Sensitivity



Bias Oscillation Dispersion

<0.5PS

Optical Return Loss

≥45dB

Fiber Connector

FC/APC or SC/APC

Noise Ratio(dB)



Connector

RJ45(SNMP) / RS232 / RS486

Power Consumption

50W

Working Voltage(V)

220VAC(90 ~ 265) or -48VDC

Working Temp(°C)

-20 ~ +85

Size(″)

19″* 15″* 1.75″

Weight(Kg)

5.0
