Help CenterWall Tile / Roof Tile Steel Forming Machine
Related Products
-
IBR Metal Sheet/cold Roll Forming MachineUS$ 24,000 - 28,000MOQ: 1 Set -
836 High Quality Corrugate Cold Bending Color Steel Roll Forming MachineUS$ 24,000 - 34,000MOQ: 1 Set
-
760 High Quality Corrugate Cold Bending Color Steel Roll Forming MachineUS$ 24,000 - 34,000MOQ: 1 Set
-
1025 Cold Wall/roof IBR Roll Forming MachineUS$ 24,000 - 32,000MOQ: 1 Set
-
820 High Quality Corrugate Cold Bending Color Steel Roll Forming MachineUS$ 24,000 - 34,000MOQ: 1 Set
Specifications
We are specialied in making Forming Machine, we can design all kinds of pattern.Forming Machine Introduction
Forming Machine consists of uncoiler and its base, coil sheet guiding equipment, film covered device, roll forming system, post-cutting equipment, hydraulic station, controlling system, supporter table.
Forming Machine Technical Parameters
Model |
HV-470B |
HV-373A |
|
Material |
Typle |
Color steel sheet |
|
Thickness(mm) |
0.4-0.7 |
||
Yield stress(Mpa) |
230-300 |
||
Max. Forming speed(m/min) |
8-12 |
||
Roller material |
45# steel with chrome |
||
Roller driven type |
Chain transmission |
||
Controller |
PLC |
||
Operation |
Touch screen and button |
||
Hydraulic system pressure(Mpa) |
12 |
||
Hydraulic station motor power(KW) |
5.5 |
||
Main motor power(KW) |
4 |
||
Total power(KW) |
9.5 |
||
Total weight(Kg) |
About 10000 |
||
Material of Forming Machine Main Equipment
Roller Material:high grade No.45 forged steel, plated hard chrome on the surface of roller with thickness 0.05mm
Active Shaft Material:high grade No.45 carbon wrought steel at Φ 75mm.
Cutter Blade:Cr12 mould steel with quenched treatment.
Electric Elements:Control system with PLC model S7-200, Siemins.transducer with ABB control panel with TP170, Siemens. It can input 10sets of spec at one time
Oil Tank Model of Hydraulic System:CB-E310
