Help CenterCorrugated Sheet Former
Related Products
Specifications
We are specialied in making corrugated sheet former, we can design all kinds of pattern.Corrugated Sheet Former Technical parameters:
1) Material spec: colored steel sheet, galvanized steel sheet
2) Thickness of coil sheet: 0.4 - 0.8mm
3) Main motor power: 7.5kW
4) Forming speed: 10 - 12m/min
5) Hydraulic station power: 3kW
6) Quantity of stands: about 16 groups
7) Hydraulic pressure: 10 - 12Mpa
8) Controlling system: PLC
9) Index error of length: 10m - 2mm
10) Total weight: about 9,500kg
11) Voltage: 380V 3 phase 60Hz or at buyer's requirement
Material of main equipment:
1) Roller material: high grade No.45 forged steel, plated hard chrome on the surface of roller with thickness 0.05mm
2) Active shaft material: high grade No.45 carbon wrought steel at diameter 75mm
3) Cutter blade: Cr12 mould steel with quenched treatment
4) Electric elements: control system with PLC model S7-200, Siemens transducer with ABB control panel with TP170, Siemens. It can input 10sets of spec at one time
5) Oil tank model of hydraulic system: CB-E310
