Tile Machine,Roof Tile Machine,Roof Forming Machine
- 0 per Month
Product Details
Type: | Tile Forming Machine | Tile Type: | Colored Steel | Use: | Roof |
Brand Name: | Tile Machine | Model Number: | WLFM18-76-836 |
Product Description
Specifications
We are specialied in making tile machine, we can design all kinds of pattern.Tile Machine Introduction
Tile machine consists of uncoiler and its base, coil sheet guiding equipment, film covered device, roll forming system, post-cutting equipment, hydraulic station, controlling system, supporter table.
Tile Machine Technical Parameters
Material Spec Colored steel sheet ; galvanized steel sheet
Thickness of Coil Sheet 0.3 --0.7 mm
Main Motor Power 7.5kw
Forming Speed 10--12m/min
Hydraulic Station Power 3kw
Quantity of Stands About 18 groups
Hydraulic Pressure 10~12Mpa
Controlling System PLC
Index Error of Length 10m±2mm
Total Weight About 1000kg
Voltage: 380V 3 phase 60Hz or at buyers requirement
Material of Tile Machine Main Equipment
Roller Material:high grade No.45 forged steel, plated hard chrome on the surface of roller with thickness 0.05mm
Active Shaft Material:high grade No.45 carbon wrought steel at Φ 75mm.
Cutter Blade:Cr12 mould steel with quenched treatment.
Electric Elements:Control system with PLC model S7-200, Siemins.transducer with ABB control panel with TP170, Siemens. It can input 10sets of spec at one time
Oil Tank Model of Hydraulic System:CB-E310
