Hydraulic Slitting and Cutting Machine

FOB Price

US$ 16,000 - 18,000 / Set

1 Set(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Zhejiang, China		Brand Name	Willing
Model Number	0.2-1X1250

High Quality Slitting Machine, Slitting Machine, cutting machine.

High Quality Slitting and Cutting Machine, Slitting Machine, Cutting Machine

1. Technical Parameters

1) Material: cold rolled steel coils /colour-coated steel coils /aluminum coils;

2) Thickness: 0.25mm ~ 1.0mm;

3) Width: max. 100 ~ 1250mm;

4) Line speed: max. 20m/min.;

5) Machine size: 1700*1300*1200mm (length * width *height);

6) Numbers of slitting: max. 9 slits;

7) Cutting accuracy: 0.02mm;

2. Standard Equipment of Machine

1) Manua Type Decoiler 1set

2) Guiding Equipment 1set

3) Slitting Equipment 1set

4) Cut to length Equipment(leveling cutting) 1set

5) Hydraulic Station 1pc

6) PLC Control Panel 1pc
