Help CenterRefractory Ceramic Fiber Paper for Insulation
Related Products
Specifications
refractory ceramic fiber paper for insulationinsulation& heat insulation ceramic fiber paper
thermal insulation ceramic fiber
Ceramic fiber paper is produced by ceramic fiber, binder and some additive through wet process, with the characteristics of stable chemical performance, resistance to most of the erosion of the chemicals. The physical property like refractory and insulation keep same when meet with oil, water or steam.
The paper is with smooth furnace and good flexibility, can be cut into suitable size. Besides, ceramic fiber paper has excellent dielectric strength; the binder will be burned out when fired.
ceramic fiber paper Data sheet:
Properties |
YESOWOOL®1000 Paper |
YESOWOOL®1260 Paper |
YESOWOOL®1400 Paper |
|
Classification Temperature°C |
1000 |
1260 |
1400 |
|
Room Temperature Properties(23°C/Relative Humidity 50%) | ||||
Color |
White |
White |
White |
|
Density kg/m3 |
210 |
210 |
210 |
|
Tensile Strength MPa |
0.50 |
0.65 |
0.65 |
|
Organic Content(%) |
≤10 |
≤8 |
≤8 |
|
Elevated temperature property | ||||
|
Linear shrinkage rate(24h) (%) |
1000x24hrs |
≤3.5 |
- |
- |
1100x24hrs |
- |
≤3.5 |
- |
|
1200x24hrs |
- |
- |
≤3.5 |
|
Thermal Conductivity |
W/(m·k) ASTM-C-201 |
|||
200°C |
0.05 |
0.05 |
0.05 |
|
400°C |
0.09 |
0.09 |
0.09 |
|
600°C |
0.13 |
0.13 |
0.13 |
|
800°C |
0.20 |
0.20 |
0.20 |
|
1000°C |
- |
- |
0.28 |
|
