We can supply lots kind of ceramic fiber modules,ceramic fiber blanket,ceramic fiber board, ceramic fiber paper.Ceramic Fiber Modules introduction:
Ceramic Fiber Modules with matched mechanical anchor fixings, ceramic fibre products, ceramic fiber paper, cermic fiber board,Ceramic fiber modules specialized manufacturer in CHINAAlumina fiber module is a new refractory lining product in order for simplifying and speeding up the furnace construction and improving the lining integrity. The product, pure white, normal size, can be directly fixed on the anchor bolt of industrial furnace steel sheet, with a good fireproof and thermal insulation, which increase the furnace refractory insulation integrity and improve the furnace lining technology. Its classification temperature (From 1050°Cto 1600°C).
Product Features of ceramic fiber modules:
- Excellent chemical stability
- Excellent thermal stability
- Excellent flexibility, the module is in pre-compression state, after the lining masonry
- The Expansion of modules enable seamless lining,fiber lining can be compensated to improve
- Insulation performance of Fiber lining, and the overall performance is good
- Excellent thermal stability and thermal shock resistance
- Ceramic fiber module can be installed quickly, and anchors set in the wall lining , which can lower the requirements of anchor Material
Typical Applications of ceramic fiber modules:
- Furnace lining and insulation of furnace in Petrochemical industry
- Furnace lining and insulation of furnace in Metallurgical industry
- Furnace lining and insulation of furnace in Ceramics, glass and other building materials industry
- Furnace lining and insulation of heat treatment furnace in heat treatment circle
- other industrial furnace lining
Technical Data of ceramic fiber modules:
| Type | Common | Standard | Zirconium | |
| Classification temperature (°C) | 1260 | 1260 | 1400 | |
| Shrinkage on heating (%) | 950°C×24h≤-3 | 1000°C×24h≤-3 | 1350×24h≤-3 | |
| Thermal conductivity by mean tem.(W/m.k)(200kg/m3) | 200°C | 0.050~0.060 | ||
| 400°C | 0.095~0.120 | |||
| 600°C | 0.160~0.195 | |||
| Density (kg/m3) | 200 | |||
| Size (mm) | 300×300×250 | |||
| Package | carton | |||
| Certificate | ISO9001-2000; ISO14001-1996 | |||
Our service of ceramic fiber modules :
We can guarantee the quality of the ceramic fiber modules with the competitive price. We will try our best to satisfied the requirement of the customer about ceramic fiber modules products. We do not want to do the one-shot business of the ceramic fiber modules . We also can provide some samples of the ceramic fiber modules products .
The picture of ceramic series:
The delivery of samples of the ceramic fiber module:
