Specifications
1. Digital Spring Fatigue Tester2. Various spiral spring
3. Adjust the amplitude and frequency of spring
TPJ-20 Digital Spring Fatigue Tester
Application:
This machine is mainly used for various spiral spring, disc springs and shock absorbers, sealsprings, and the fatigue life of test. Widely used in spring, shock absorber production, application, etc.
Technical parameter:
Model | TPJ-1/2/3/5/10/20 |
Max testing force | 1/2/3/5/10/20KN |
Frequency | 0.5-5 HZ( as you required) |
Amplitude | ±50mm (as you required) |
Counter capacity | 9×109 |
Test spring max diameter | 150~260mm |
Test spring free length | 390mm (as you required) |
Spring test number | 250kg*8 |
Working voltage | 220V/50HZ |
Main features:
1. According to the technical requirements of the spring, adjust the amplitude and frequency of spring
2. LCD,testing time and frequency according to requirements can be input program,finished testing automatically.
3. Preset testing time ,automatic stop
4. Easy operation,working stability.
Hensgrand Factory TPJ-20 Digital Spring Fatigue Tester
CE Certificate:
Send Inquiry to This Supplier
