Help CenterWcdma 3g Module MF206A Zte WCDMA HSDPA Module for Android
Related Products
-
Zte Mg3732 Module 3g Gsm Wcdma ModuleNegotiableMOQ: 10 Pieces -
Zte Cdma1x Module Evdo Rev A ModuleNegotiableMOQ: 1 Piece
-
Zte Hspa+ Module 3g Wcdma Module Mf226NegotiableMOQ: 1 Piece
-
Quad Band GSM GPRS Module SIM800HNegotiableMOQ: 300 Pieces
-
Wcdma Zte Hsdpa 3g Module MF206A 850/1900/2100MHz ,900/1900/2100MHzNegotiableMOQ: 1 Piece
1-Specifications: WCDMA module
2-Network:WCDMA/HSDPA
3-Frequency band:UMTS 850(900)/1900/2100MHz
GSM/GPRS/EDGE 850/900/1800/1900MHz800MHz
4-USB:2.0
5-interface:LGA TypeII 108PIN
high performance For ZTE Corporation' s MF206A WCDMA module
1-high performance reliable wifi module
2-low price with high quality wireless module
high performance For ZTE Corporation' s MF206A wifi module
With the LGA interface,the module is widely used on the products like Tracking solution,Tablet,CPE,Security protection and much more
Technical parameters
Network: WCDMA/HSDPA
Frequency band: UMTS 850(900)/1900/2100MHz
GSM/GPRS/EDGE 850/900/1800/1900MHz800MHz
Dimensions: 36*26*2.5mm
Working temperature: -30°C~+75°C
Voltage: 3.4V~4.2V/typical 3.8V
Interface: LGA TypeII 108PIN
USB: 2.0
Driver: Windows XP/7, Android2.3/4.0,Linux 2.6.20 and later ,WinCE5.0/6.0
Data rate: DL:3.6Mbps/UL:384Kbps
Commands: Standard AT commands & ZTE exclusive commands
Certifications: CE/FCC/ROHS/PTCRB/IC/WEEE/AT&T
Function: Data/SMS/MMS/GPS
Highlights: Low Cost
AT&T approval certificate
