3g Wireless Module 3g Hsdpa Module Zte Hsdpa Mf210
Negotiable
MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
ZTE
Model Number:
MF210
Payment & Shipping
Payment Methods:
Port of Shipment:
HK
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
HUAWEI MU509 3g ModuleNegotiableMOQ: 10 Pieces -
WCDMA HSPA+ Modem,WCDMA HSDPA Modem,EVDO HSDPA Modem,TDSCDMA Modem,GSM/GPRS Modem,CDMA 1X Modem,industry ModemNegotiableMOQ: 1 Piece
-
EVB Board MC8630,zte Cdma Evb Board UsbNegotiableMOQ: 1 Piece
-
Zte EVDO 800MHz Rev.A Module Mc8630NegotiableMOQ: 1 Piece
-
HUAWEI 3G WCDMA HSDPA MU509 Module 900/2100MHz GSM850/900/1800/1900MHz GSM850/900/1800/1900MHzNegotiableMOQ: 1 Piece
Place of Origin
Guangdong, China
Brand Name
ZTE
Model Number
MF210
1.It can support WCDMA/HSDPA/HSUPA 850(900)/1900/2100MHz frequency band, and GSM/GPRS/EDGE 850/900/1800/ 1900MHz frequency band.
2.It can provide the WCDMA/HSDPA/HSUPA high-speed data access service under the mobile environment.
3.It can support the short message service and GPS function.
4.It provides the standard PCI Express Mini Card power interface, U(S)IM card interface (3.0V/1.8V), USB2.0 interface and the reserved interface, etc.
| Major Technical Parameters | |||
| Name | Parameter Item | Specifications | |
| Mechanical Feature | Dimensions | 51mm * 30mm * 4.7mm | |
| Weight | About 10g | ||
| Encapsulation type | PCI Express Mini Card | ||
| Baseband | Processor architecture | ARM 9 architecture | |
| (U)SIM/SIM |
Standard 6 PIN SIM card interface 3V SIM card and 1.8V SIM card |
||
| Memory | SDRAM/NAND: 32MByte/64MByte | ||
| USB interface | USB 2.0 HIGH SPEED | ||
| Maximum power consumption | 2.3W | ||
| Voltage | DC 3. 3V | ||
| Working current2 | Peak current | ≤1.3 A | |
| Average normal working current | ≤680mA | ||
| Average normal working current(without services) | ≤75mA | ||
| Standby current | About 3.9mA | ||
| RF | GSM band | EDGE/GPRS/GSM: 1900/1800/900/850MHz | |
| UMTS band | HSUPA/HSDPA/WCDMA: 2100/1900/850(900)MHz; | ||
| RxDiv Band | 2100/1900/850(900)MHz | ||
| Max. transmitter power | UMTS2100/1900/850(900): Power Class 3 (+24dBm+1/-3dBm) | ||
| GSM/GPRS 850MHz/900MHz: Power Class 4 (+33dBm±2dBm) | |||
| GSM/GPRS 1800MHz/1900MHz: Power Class 1 (+30dBm±2dBm) | |||
| EDGE 850MHz/900MHz: Power Class E2 (+27dBm ±3dBm) | |||
| EDGE 1800MHz/1900MHz: Power Class E2 (+26dBm-4/+3dBm) | |||
| Receiving sensitivity | WCDMA2100 : ≤-106.7dBm | ||
| WCDMA1900/850 : ≤-104.7dBm | |||
| WCDMA900 : ≤-103.7dBm | |||
| GSM850/900/1800/1900 : ≤-102dBm | |||
| Equalization | Support | ||
| Main antenna interface | Support | ||
| Receive diversity (GPS) antenna interface |
Support GPS bonding pad interface, support diversity antenna interface, do not support RxDiv and GPS at the same time. ZTE does not provide the antenna, which should be provided by the 3rd-party. |
||
| Technical Standard | Data rate | GSM CS: UL 9.6kbps/DL 9.6kbps | |
| GPRS: Multi-slot Class 10 | |||
| EDGE: Multi-slot Class 12 | |||
| WCDMA CS: UL 64kbps/DL 64kbps | |||
| WCDMA PS: UL 384kbps/DL 384kbps | |||
| HSDPA: DL 7.2Mbps (Category 8) | |||
| HSUPA: UL5.76Mbps (Category 6) | |||
| GPRS type | Class B | ||
| 3GPP protocol | R99, R5, R6 | ||
| Operating system | Windows XP (SP2 and later) | ||
| Windows Vista | |||
| Windows 7 | |||
| Linux | |||
| Android | |||
| Environment Feature | Working temperature | -25 to 60° C | |
| Storage temperature | -40 to 85° C | ||
| Humidity | 5%~ 95% | ||
| Application | RAS dialup | Support | |
| SMS | Support | ||
| GPS/AGPS | Support | ||
| Network locking | Support | ||
| Upgrade | Support | ||
