14.4/3.6Mbps industry usb 3G modem
- 100000 Piece / Pieces per Month
- Shenzhen
-
Cisco Fiber Switches N9K-C93180YC-FX
-
SIERRA AR7586
-
Quectel LC29D GPS Beidou Inertial Guidance Module
-
telit 4G module LE910C4-NF
-
Acrel 4G LORA communication AWT200-1E4S1-4G/LR Intelligent data communication gateway, supports 4-way serial port
-
Acrel Wireless communication terminal Supports centralized collection of up to 10,000 points AWT200-1E8SL
Product Details
| Place of Origin: | Guangdong, China | Brand Name: | HEAD WEBLINK | Model Number: | HDM1003GW |
Product Description
2G/3G/4G LTE Industry Modem
Frequency bands.
3G MODEM.
1. HDM1003GW. WCDMA 850/1900 MHz or 900/2100MHz
2. HDM1003GE. EVDO 800 MHz
2G MODEM.
1.HDM1002GG. GSM/GPRS,850/900/1800/1900MHz
2.HDM1002GC. CDMA 1X,800MHz
Specifications.
3G MODEM.
1. HDM1003GW. data rate, DL,14.4Mbps ,UL:5.76Mbps
2. HDM1003GE. data rate, DL,3.1Mbps ,UL:1.8Mbps
2G MODEM.
1. HDM1002GG. GSM/GPRS,DL 85.6Kbps, UL,85.6Kbps
2. HDM1002GC. CDMA 1X,DL 153.6Kbps, UL,153.6Kbps
Interfaces.
• +5~+30V. connector for power supply connection
• RS232 or RS485. Plug-in terminal connector.
• SMA antenna connector .
• LED. Network status indicator, Power supply status indicator.
• USB. USB power supply and data communication port. (3G/4G LTE only)
• SIM/UIM. SIM/UIM card connector
Temperature.
Operating Temperature Range. -30℃~+75℃
Storage Temperature Range. -40℃~+85℃
Physical parameters.
Aluminum alloy shell
Dimension less than. 57 * 100 * 25 mm
Weight less than: 120 g
Highlight.
With watchdog funtion.Keep on online continuously.
| Function | Description |
Standard | 1.WCDMA HSPA+ modem 2.WCDMA HSDPA modem 3.EVDO HSDPA modem 4.TDSCDMA modem 5.GSM/GPRS modem 6.CDMA 1X modem |
Interface | 1. 3G modem use USB interface 2. 2G/2.5G modem use UART interface |
Indicator light | Network status indicator |
Power supply | 5V,2000mA |
| Dimensions | 105*75*29mm |
| Weight | About 120g |
