lte tdd 4g waterproof industrial router
Feature.
1. Support 3G or 4G LTE network.
2. MIMO RF dual antenna
3. Waterproof and dustproof IP65. Can be mounted on roof.
4. Lightning protection
5. With SIM card slot.
6. Automaticlly dial-up access to the Internet after boot .
7. One ethernet interface.It can be extended 100m long of the ethernet cable.
8. Built-in dial-up parameters more than 200 operators.
9. We can customize 3G/4G LTE frequency bands for customers.
10. Dimensions:130*55*26mm
Product specification.
* 3G router.
Operating temperature: -20°C -- +60°C
Operating humidity: 5%--95%
Operating frequency:
1). HDR1003GWUO:
WCDMA:(850)900/1900/2100MHz
GSM: 850/900/1800/1900MHz
2). HDR1003GWO+:
WCDMA:850/1900MHz & 900/2100MHz
GSM: 850/900/1800/1900MHz
3). HDR1003GEO:
EVDO 800MHz & 800/1900MHz
The rate and network mode:
1). HDR1003GWUO:
WCDMA: DL 7.2MbpS, UL 5.76MbpS
2).HDR1003GWO+:
WCDMA: DL 14.4MbpS, UL 5.76MbpS
3).HDR1003GEO:
EVDO:DL 3.1Mbps, UL 1.8Mbps
*Note: We can provide customized frequency bands or network mode.
* 4G LTE Router.
1).HDR1004GTO.
TDD-LTE. Band 38, Band 39, Band 40 2570~2620MHz/1880~1920MHz/ 2300~2500MHz
FDD-LTE. Band 7 UL. 2500MHz-2570MHz, DL. 2620MHz-2690MHz
TD-SCDMA.1880~1920MHz/2010~2025MHz
GSM. 900MHz/1800MHz
2).HDR1004GFO
Latin-America version.
FDD- LTE. 2100/1900/1700/850/900/2600/700MHz Band 1,2,4,5,7,8,12&17
TDD- LTE. Band 38
WCDMA/UMTS .2100/1900/1700/850(900)MHz
GSM/GPRS. 850/900/1800/1900MHz.
EU_Asia version.
FDD- LTE. Band 1,3,7,8,20
TDD- LTE. Band 38,40
WCDMA/UMTS . 2100/1900/1700/850(900)MHz
GSM/GPRS. 850/900/1800/1900MHz
*Note: We can provide customized frequency bands.
Datarate:
*4G router.
1).HDR1004GTO.
TDD LTE: DL,100MbpS, UL,50Mbps
FDD LTE: DL,100MbpS, UL,50Mbps
TD-SCDMA: DL 2.8MbpS;UL 2.2MbpS
2).HDR1004GFO
FDD LTE: DL,100MbpS, UL,50Mbps
TDD LTE: DL,61MbpS, UL,18Mbps
WCDMA: DL 14.4MbpS;UL5.76MbpS
*3G router.
1). HDR1003GWUO:
WCDMA: DL 7.2MbpS, UL 5.76MbpS
2).HDR1003GWO+:
WCDMA: DL 14.4MbpS, UL 5.76MbpS
3).HDR1003GEO:
EVDO:DL 3.1Mbps, UL 1.8Mbps
*Note: We can provide customized the frequency bands and the data rates.
Test environment.
ESD,Waterproof and dustproof, Lightning protection,Temperature(-30~+70).
