3g industry industry industry router or cpe or cpe ,4g industry industry industry router or cpe or cpe

Frequency band

  * 4G LTE router.

1). HDR1004GTI.

      TDD-LTE. B38, B39, B40,B41

   FDD-LTE.  B1,B3,B7

   TD-SCDMA.1880~1920MHz/2010~2025MHz

   GSM.  900MHz/1800MHz

 2). HDR1004GFI

Lartin America version.

   FDD- LTE. B1,B2,B4,B5,B7,B8,B12,B17

   TDD- LTE.  B38

   WCDMA/UMTS . 2100/1900/1700/850(900)MHz

   GSM/GPRS. 850/900/1800/1900MHz.

EU_ASIA version.

        FDD- LTE. B1,B3,B7,B8,B20

        TDD- LTE. B40

        WCDMA/UMTS . 2100/1900/1700/850(900)MHz

        GSM/GPRS. 850/900/1800/1900MHz

 * 3G router.

1). HDR1003GWUI

  WCDMA. (850)900/1900/2100MHz

    GSM. 850/900/1800/1900MHz

2). HDR1003GWI+

   WCDMA. 850/1900MHz  & 900/2100MHz

     GSM. 850/900/1800/1900MHz

3). HDR1003GEI:

         EVDO 800MHz &  800/1900MHz

*Note.

 We can provide customized frequency bands.

 Data rates

* 4G LTE router.

1).HDR1004GTI.

    TDD LTE.  DL,100Mbps   UL,50Mbps

    FDD LTE.  DL,100Mbps    UL,50Mbps

    TD-SCDMA.  DL 2.8Mbps  UL 2.2Mbps

2). HDR1004GFI

    FDD LTE. DL,100Mbps  UL,50Mbps

  TDD LTE. DL,50Mbps    UL,25Mbps

  WCDMA. DL 14.4Mbps   UL5.76Mbps

* 3G router.

1). HDR1003GWUI

         WCDMA. DL 7.2Mbps, UL 5.76Mbps

2).HDR1003GWI+

  WCDMA. DL 14.4Mbps, UL 5.76Mbps

3).HDR1003GEI

  EVDO. DL 3.1Mbps, UL 1.8Mbps

  Power supply

   Input. 100V~240V,50Hz~60Hz

       Output. 15V,1000mA

 Conditions

      Operating Temperature . -20℃ -- +60℃

      Operating humidity. 5%--95%
