Home > Products > Paper Bag Machine > Simple Kraft Paper Treat Bag Paper Bag Making Machine Price
Simple Kraft Paper Treat Bag Paper Bag Making Machine Price
- 35 Set / Sets per Month
- NINGBO
- T/T D/P D/A Credit Card PayPal
- Toilet Paper Cutter/Kitchen Towel Cutting Machine Price with High Performance
- High Capacity 3200mm A3 A4 Paper Writing Paper Recycling Machine, Office Paper Product Machinery for Sale
- Best Price 3200 Model Office Paper Copy Paper Manufacturing Line with Good Reputation
- Henan Toilet Tissue Paper Cutter/Cutting Machine with High Quality
- 1880mm Type Napkin Paper Making Machine Made in China
- Manufacturer Supply1575mm Napkin Paper/Tissue Paper Manufacturing Machine
Product Details
Condition: | New | Product Type: | Paper Bag Making Machine | Processing Type: | Paper Folding Machine |
Place of Origin: | Zhejiang, China | Brand Name: | XIAOHAI | Model Number: | CY-400 |
Voltage: | 380V,50/60HZ,3phases | Power(W): | 10kw | Dimension(L*W*H): | 400*2100*1900mm |
Weight: | 2500kg | Certification: | CE | Warranty: | one years |
After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Specifications
Simple Kraft Paper Treat Bag Paper Bag Making Machine Price1. Easy operation
2.Low power consumption
3. Fully Automatic
Simple Kraft Paper Treat Bag Paper Bag Making Machine Price
1. Features:
Paper Bag Making Machine can make paper bags in one process from roll paper, edge folding, tube
forming, cutting, gluing, bottom folding, bottom gluing and finishing bag.
It is an ideal machine for producing Sharp Bottom food bags like bread bags, KFC bags and
Mcdonald's bags etc.
2. Advantages:
1)Suited for 40-80gsm paper.
2)Controls bag length through the human-machine interface.
3)PLC system for calculating parameters.
4)Equipped with an accurate photocell system.
5) Color mark error automatic alarming and stopping system
6)Automatic oil lubrication system and Automatic counting system
3.Technical Parameters:
Paper Weight | 40-80g/m2 |
Bag Length | 160-420mm |
Bag Width | 70-260mm |
The width of paper roll | 260-720mm |
Speed | 100-400pcs/min |
Total Power | 10kw |
Power Voltage | 380v,50/60 HZ, 3 phases |
Total Weight | 2500kg |
Machine Dimension(L*W*H) | 400*2100*1900mm |
4.Configuration Brand and details:
Name andSpecification | Quantity | Brand, Country |
Servo Motor | two sets | YASKAWA, Janpan |
PLC | 1pc | Delta ,Taiwan |
Touch Screen | 1pc | Weinview ,Taiwan |
Photo-cell | 2pc | Sick, Germany |
Web Edge Control(EPC) | 1pc | China |
Frequency Converter(Inverter) | 1pc | China |
5.Machine Pictures:
6. Sample Pictures:
7. Machine Package Pictures:
We are specializing in making paper bag making production line, including paper bag making machine,
flexo printing machine, rope making machine and handling making machine etc. We have both paper
bag making machine with roll feeder and sheet feeder.
1. Factory Show:
2. Certificates
3. Advantages&Service
1 We have several senior engineers service in many countries, all the year round with our after-sales office in multiple countries.
2 Machines with good quality in one year, life-long maintenance.
3 We have many machines can be monitored via the Internet, solve customer requirements in a timely manner.
4 We have several senior,continuous innovation and reform, in order to ensure the quality of mechanical stability.
5 Undertake various non-standard machinery, solve the customers' requirements.
