Specifications
20A 12V/24V Dual Battery Solar Charger Controller Regulator for caravan and boatPWM charge mode
20A,12V/24V
1 year warranty
20A 12V/24V Dual Battery Solar Charger Controller Regulator for caravan and boat
Features
Micro controller digital accuracy
PWM Charge mode
State of charge (SOC)
Temperature compensation
Automatic detection of the voltage
External temperature sensor
Remote temperature sensor (option)
Remote meter MT-1(option) shows the working data and condition
Battery type option
Battery AH setting
Charging priority setting
Modify parameters through four keys
Microcontroller digital accuracy.
PWM Charge mode
State of charge (SOC)
Temperature compensation
Automatic detection of the voltage
External temperature sensor
Remote temperature sensor (option)
Remote meter MT-1(option) shows the working data and condition
Battery type option
Battery AH setting
Charging priority setting
Modify parameters through four keys
Setpoint |
Sealed battery |
Flooded battery |
Gel battery |
Boost voltage |
14.2V |
14.4V |
14.6V |
Equalization voltage |
14.4V |
14.6V |
14.8V |
Float voltage |
13.7V |
13.7V |
13.7V |
Maximum solar voltage |
30V(or 55V) |
||
Battery voltage range |
1-15V |
||
Boost time |
30 minutes |
||
Self-consumption |
4mA at night, 10mA at charging |
||
Meterbus connection |
8-pin RJ-45 |
||
Temp. compensation |
-30mV/12V |
||
Terminals |
4mm2 |
||
Temperature |
-35 to +55 celsius degree |
||
Note: all the data is for 12V, for 24V, please use 2x. | |||
WARRANTY: One year warranty period. | |||
