Specifications
40A 12V/24V SOLAR CONTROLLER FOR SOLAR POWER SYSTEM WITH DIGITAL AND SYMBOL DISPLAYPWM or ON/OFF option
one year warranty
CE
40A 12V/24V SOLAR CONTROLLER FOR SOLAR POWER SYSTEM WITH DIGITAL AND SYMBOL DISPLAY
EPIP is the second generation with high quality and reliability. Adds new features and protections using highly advance technology .Provides longer battery life and improved system performance .Sets new standards for reliability and
self-diagostics
Features
Microcontroller digital accuracy.
PWM or ON/OFF series battery charging options.
State of charge (SOC).
Temperature compensation.
Automatic detection of the voltage.
Temperature compensation .Remote temperature sensor.
Battery Ah setting, boost charging, equalizing charging, float charging
Automatic load reconnection, manual load switch
Adjustable parameters by four buttons
Load control option: ON/OFF, Dusk-to-Dawn, On + setting hours, setting time ON/OFF.
Electronic protection
Short circuit protection
Reverse polarity protection
Reverse current protection at night
Over charging or discharging protection
Over load protection
Display
LCD display: SOC as a fuel gauge, all system parameters in digital value, system status as symbols
Technical specification
EPIP602 series: 12/24 VOLT auto work, 40A, 50A, 60 AMPS (for PV and load)
24/48V VOLT auto work, 30A, 40A, 50A, 60 AMPS (for PV and load)
Equalization voltage: 14.8 Volt
Boost voltage: 14.4 Volt
Float voltage: 13.6 Volt
Low voltage disconnect (LVD) 11.1 Volt.
Low voltages reconnect (LVR): 13.1Volt.
Temperature compensation: -30mv/°C/12V.
Self-consumption: 6mA maximum
Terminals: for wire sizes to 16mm2
Temperature: -35°C to +55°C
Notes: It is for 12V system. Please X2 for 24V system.
Warranty: ONE YEAR.
